Description
LSCC Conveyor Clutches LSCC-44 1.000 BORE,PILOT,NSB
View AllClose
| Features: | Splined Hub Minimizes Binding That Can Cause Problems With Competitive Hex Driven Products. |
| Comments: | "Ideal For Use In Conveyors And Other Low RPM, High Torque Applications" |
| Open Or Enclosed Design: | Open |
| Drive Arrangement: | Pilot Mount |
| Bore Size: | 1.000 in. |
| Bore Style: | Straight With Keyway And 3 Setscrews |
| Pilot Size: | 3.000 in. |
| Pilot Or Drive Flange Bolt Circle Data: | "4, 0.250""-20 Bolts @ 90° On A 3.500 in. Circle" |
| Length: | 5.02 in. |
| Clutch Facing Type: | Standard Coefficient |
| Clutch Facing Edge Color Code: | Red |
| Maximum Static Clutch Torque: | 2110 inlbs |
| Minimum Sprocket Size: | "25/60T, 35/40T, 40/31T, 50/25T, 60/22T" |
| Drive Inertia: | 6.46 lbin² |
| Shaft Inertia: | 2.54 lbin² |
| Max Rpm: | "250 @ 80 psi, 300 @ 70 psi, 350 @ 60 psi, 450 @ 50 psi, 750 @ 40 psi" |
| Actuation/Return: | Air/Spring |
| Port Size: | 0.125 NPT |
| Maximum Operating Pressure: | 80 psi |
| Minimum Engagement Pressure: | 5 psi |
| Temperature Range: | 32 - 150 °F |
| Clutch Air Chamber Volume When New: | 2.399 in³ |
| Clutch Air Chamber Volume When Worn Out: | 4.516 in³ |
| Ratings: | "CE, And RoHS" |
| Finish: | Machined Aluminum |
| Outer Diameter: | 4.56 in. |
| Shipping Weight: | 11.0 LB |
