Nexen 927203 Multi-Caliper Tension Brake
NexenMulti-Caliper Tension Brake
STB600*1.125 BORE
Air Engaged, Shaft Mount, Multi-Caliper, Air Cooled, Medium Duty
Length=3.86 in; Outer Diameter=6.62 in; Bore Size=1.125 in, Machined Bore with Keyway
Product Features=Air Engaged, Shaft Mount, Multi-Caliper, Air Cooled, Medium Duty; Braking Capability=Continuous Slip, E-Stop, Holding
- Weight:
- 9.5 lbs
- Mounting Style:
- Shaft
- Anti Rotation Style:
- Anti-Rotation Holes
- Engagement Method:
- Air
- Release Method:
- Spring
- Max Speed:
- 3600 RPM
- Shaft Inertia:
- 16.7 lbin²
- Open Or Enclosed Design:
- Open
- Primary Finish:
- Bare Aluminum
- Min Ambient Temperature:
- 32 °F
- Max Ambient Temperature:
- 150 °F
- CE Certified:
- CE
- RoHS Compliant:
- RoHS
- Bore Details:
- Straight
- Brake Facing Type:
- Standard Coefficient (Kevlar Low Dust)
- Brake Facing Edge Color Code:
- Red
- Approximate Brake Facing Life:
- 194 hphr
- Brake Facing Effective Area:
- 5.0 in²
- Max Brake Continuous Thermal Dissipation:
- 0.72 hp
- Max Dynamic Torque With Small Pistons:
- 85 inlb
- Max Dynamic Torque With Medium Pistons:
- 133 inlb
- Max Dynamic Torque With Large Pistons:
- 189 inlb
- Max Dynamic Torque With All Calipers:
- 407 inlb
- Max Operating Pressure:
- 85 psi
- Min Engagement Pressure:
- 1 psi
- Inlet Size:
- 0.125 NPT, Or 5/32 in Plastic Tubing Fitting Included
- Bore Style:
- Machined Bore with Keyway
- Materials Of Construction:
- Machined Aluminum
- Output Shaft Style:
- None
- Actuation Type:
- Multiple Actuators, 6 Diaphragm Actuators, 2 Small, 2 Medium, 2 Large
