Schneider Electric 8501RS44V20 Relay250Vac15Amptyper+Options

Schneider Electric 8501RS44V20 Relay250Vac15Amptyper+Options

Schneider Electric
SKU:
8501RS44V20
|
UPC:
785901137177
Availability:
Contact us to confirm availability and lead times.
$54.05
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
8501RS miniature plug in relays are designed for control circuit logic applications. These relays are designed to be plugged into a relay socket. This makes for very easy replacement. This relay plugs into an 8501NR34 or 8501NR34B relay socket. Relay is available with 4PDT contact arrangements. It has four normally open and four normally closed contacts. The contacts have a 15 ampere resistive rating at 277 VAC and at 28VDC, a 10 ampere resistive rating at 277 VAC, a 1/2 HP rating at 120 VAC, a 1 HP rating at 277 VAC and a B300 inductive rating. Relays can be ordered with a wide variety of coil voltages. This relay has a 120 VAC nonreplaceable coil. Relay does not have a green LED indicator. 8501RS relays are UL listed with Square D relay sockets, UL component recognized and CSA certified.
Additional Information
Maximum Switching Voltage:
300 V AC || 30 V DC
Control Type:
without test button
Switch Function:
4PDT
Environmental Disclosure:
ENVPEP1511008EN
Circularity Profile:
N/A
Product Compatibility:
8501NR34
Local Signalling:
no indicator
California Proposition 65:
WARNING: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other repr
Reach Regulation:
Free of Substances of Very High Concern above the threshold
Range Of Product:
8501R
Depth:
41.8 mm
Rohs Exemption Information:
Yes
Operating Time:
20 ms - pick-up || 20 ms - drop-out
Shape Of Pin:
spade
Product Certifications:
UL Listed || UL Recognized || CSA || CE
Eu Rohs Directive:
Pro-active compliance (Product out of EU RoHS legal scope)
Width:
40.6 mm
Relay Type:
standard
Height:
27.3 mm
Warranty:
18 months
Rated Power In Hp:
0.5 120 V AC || 1 277 V AC
Contacts Material:
silver alloy, gold flashed
[Uc] Control Circuit Voltage:
120 V AC
Mounting Support:
socket
Ambient Air Temperature For Operation:
-40-131 °F
Rated Breaking Capacity:
3 A 120 V AC inductive control circuit UL 508 || 1.5 A 240 V AC inductive control circuit UL 508 || 10 A 120 V AC resistive control circuit UL 508 || 6.67 A 277 V AC resistive control circuit UL 508 || 10 A 28 V DC resistive control circuit UL 508
China Rohs Regulation:
X
Sustainable Offer Status:
Green Premium product
Reach Free Of Svhc:
Yes
Product Or Component Type:
Miniature Relay
