Schneider Electric 8536SAO12V06 NEMA Motor Starter, Type S, nonreversing, Size 00, 9A, 2 HP at 460 VAC, 5 kA SCCR, 3 phase, 3 pole, melting alloy, 480 VAC coil, open

(No reviews yet) Write a Review
SKU:
8536SAO12V06
MPN:
8536SAO12V06
Condition:
New
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Nema Size:
0
Rated Power In Hp:
1.5 HP 200 V AC || 1.5 HP 230 V AC || 2 HP 460 V AC || 2 HP 575 V AC
Electrical Connection:
screw clamp terminals
Warranty:
18 months
[Uc] Control Circuit Voltage:
440 V AC 50 Hz || 480 V AC 60 Hz
Motor Starter Type:
non reversing
Auxiliary Contact Composition:
without
Product Or Component Type:
motor starter
Range Of Product:
S
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Control Circuit:
common control circuit
Local Signaling:
without pilot light
California Proposition 65:
WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Line Rated Current:
0.375
Pvc Free:
Yes
Nema Degree Of Protection:
not rated (open device)
Control Type:
no control units
[Ue] Rated Operational Voltage:
600 V AC
Thermal Overload Type:
melting alloy 3
Depth:
107 mm
Phase:
3 phase
Country of Origin:
United States
Product Certifications:
UL Listed || CSA || NEMA
Eu Rohs Directive:
Not compliant
Poles Description:
3P
$386.00

Description

Type S NEMA motor starters are used for full voltage starting and stopping of AC squirrel cage motors. Type S motor starters have ratings up to 810 amperes. This 3 pole NEMA Size 00 non-reversing starter has an 9 ampere rating. This NEMA Size 00 motor starter has 3 phase ratings of 1.5 HP at 220 and 230 VAC and 2 HP at 460 and 575 VAC. This non-reversing NEMA motor starter has a melting alloy type overload relay that uses Type B thermal units to sense over current conditions. This NEMA starter has a 5 kA maximum SCCR (Short Circuit Current Rating) per UL508A when protected by an appropriate circuit breaker or fuse. Type S motor starters are available with replaceable coils in a wide variety of voltages. This starter has a 440/480 VAC 50/60 Hz operating coil wired for common control. This NEMA starter is an open device without an enclosure. This starter is 6.77 inches tall, 3.50 inches wide and 4.22 inches deep. A wide variety of accessories are available for Type S starters. Type S non-reversing NEMA motor starters are UL listed and CSA certified.
