Schneider Electric 8536SCO3V03 NEMA motor starter, Type S, nonreversing, Size 1, 27A, 10HP at 460VAC, 5kA SCCR, 3 phase, 3 pole, melting alloy, 240VAC coil, open

(No reviews yet) Write a Review
SKU:
8536SCO3V03
MPN:
8536SCO3V03
Condition:
New
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Electrical Connection:
screw clamp terminals
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Product Or Component Type:
motor starter
Line Rated Current:
27 A
Poles Description:
3P
Thermal Overload Type:
melting alloy 3
Product Certifications:
UL Listed || CSA || NEMA
California Proposition 65:
WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
[Ue] Rated Operational Voltage:
600 V AC
Eu Rohs Directive:
Not compliant
Pvc Free:
Yes
Control Circuit:
common control circuit
Control Type:
no control units
Depth:
107 mm
Warranty:
18 months
Motor Starter Type:
non reversing
Auxiliary Contact Composition:
without
Country of Origin:
United States
Rated Power In Hp:
7.5 HP 200 V AC || 7.5 HP 230 V AC || 10 HP 460 V AC || 10 HP 575 V AC
[Uc] Control Circuit Voltage:
220 V AC 50 Hz || 240 V AC 60 Hz
Nema Size:
1
Phase:
3 phase
Local Signaling:
without pilot light
Range Of Product:
S
Nema Degree Of Protection:
not rated (open device)
$557.00

Description

Type S NEMA motor starters are used for full voltage starting and stopping of AC squirrel cage motors. Type S motor starters have ratings up to 810 amperes. This 3 pole NEMA Size 1 non-reversing starter has a 27 ampere rating. This NEMA Size 1 motor starter has 3 phase ratings of 7.5 HP at 200 and 230 VAC and 10 HP at 460 and 575 VAC. This non-reversing NEMA motor starter has a melting alloy type overload relay that uses Type B thermal units to sense over current conditions. This NEMA starter has a 5 kA maximum SCCR (Short Circuit Current Rating) per UL508A when protected by an appropriate circuit breaker or fuse. Type S motor starters are available with replaceable coils in a wide variety of voltages. This starter has a 220/240 VAC 50/60 Hz operating coil wired for common control. This NEMA starter is an open device without an enclosure. This starter is 6.77 inches tall, 3.50 inches wide and 4.22 inches deep. A wide variety of accessories are available for Type S starters. Type S non-reversing NEMA motor starters are UL listed and CSA certified.
