Schneider Electric 9001KA41 30Mm Contact Block 1No/1Nc Logic Reed
This Harmony 9001K, hermetically sealed contact block uses screw-clamp terminals and has 1 x NO + 1 x NC contact. This contact block allows fast and easy replacement and configuration of your push buttons and selector switches. It is easily installed and replaced on 9001K complete push button units and selector switches and connects to control circuits with simple screw-clamp connections. Its clear color of cover allows users to identify it visually at a distance. It protects operators from unexpected contact with live circuits thanks to its IP20 protection index. It is compatible with Harmony 9001K push buttons and switches. Its wide range of operating temperatures from -25°C to 70°C allows versatility in usage of product.
- Contact Operation:
- logic reed || hermetically sealed
- Weee:
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
- Circularity Profile:
- N/A
- [Ie] Rated Operational Current:
- 3 A 240 V, AC-15, A600-Q600 NEMA || 0.55 A 125 V, DC-13, A600-Q600 NEMA
- Device Short Name:
- 9001K
- [Ui] Rated Insulation Voltage:
- 250 V 3)IEC 60947-1
- Tightening Torque:
- 0.8-0.8 N.m IEC 60947-1
- Environmental Disclosure:
- ENVPEP121006EN
- Shape Of Screw Head:
- cross slotted
- Short-Circuit Protection:
- 10 A cartridge fuse IEC 60947-5-1
- Rated Breaking Capacity:
- 3 kA 240 V AC-15, 720 VA || 6 kA 120 V AC-15, 720 VA || 1.2 kA 600 V AC-15, 720 VA || 1.5 kA 480 V AC-15, 720 VA || 0.1 kA 600 V DC-13 || 0.27 kA 250 V DC-13 || 0.55 kA 125 V DC-13
- Standards:
- CSA C22.2 No 14 || IEC 60947-5-4 || UL 508 || JIS C 4520 || JIS C 852 || IEC 60947-5-1 || IEC 60947-1 || UL 60947-5-1
- Connections - Terminals:
- screw clamp terminals, 1 x 0.22...2 x 2.5 mm² IEC 60947-1
- Ambient Air Temperature For Operation:
- -25-70 °C
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Range Of Product:
- Harmony 9001K || Harmony 9001SK
- Mercury Free:
- Yes
- China Rohs Regulation:
- X
- Warranty:
- 18 months
- Ambient Air Temperature For Storage:
- -40-70 °C
- Shock Resistance:
- 50 gn IEC 60068-2-27
- [Us] Rated Supply Voltage:
- 120 V
- Connections - Terminals:
- screw-clamp terminals
- Product Or Component Type:
- contact block
- Sustainable Offer Status:
- Green Premium product
- Electrical Shock Protection Class:
- class II IEC 61140
- [Icm] Rated Short-Circuit Making Capacity:
- 12 kA 600 V AC-15, 7200 VA || 15 kA 480 V AC-15, 7200 VA || 30 kA 240 V AC-15, 7200 VA || 60 kA 120 V AC-15, 7200 VA || 0.55 kA 125 V DC-13 || 0.1 kA 600 V DC-13 || 0.27 kA 250 V DC-13
- Ip Degree Of Protection:
- IP20 IEC 60529
- Contacts Type And Composition:
- 1 C/O
- Vibration Resistance:
- 7 gn 2-500 Hz)IEC 60068-2-6
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other repr
- Protective Treatment:
- TC
- Contacts Usage:
- hermetically sealed contacts
- [Uimp] Rated Impulse Withstand Voltage:
- 2.5 kV IEC 60947-1
- [Ith] Conventional Free Air Thermal Current:
- 0.416666666666667
- Product Certifications:
- UL 508 || NEMA
- Rohs Exemption Information:
- Yes
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Net Weight:
- 0.045 kg
- Positive Opening:
- without
