Schneider Electric 9001KP1A31 Pilot Light 120Vac 30Mm Type K +Options

Schneider Electric 9001KP1A31 Pilot Light 120Vac 30Mm Type K +Options

Schneider Electric
SKU:
9001KP1A31
|
UPC:
3389118041493
$153.00
(No reviews yet) Write a Review
Condition:
New
Current Stock:
Description
This Harmony 9001K, amber pilot light with transformer and plastic fresnel is supplied with 110V AC. It has a chromium-plated metal bezel. This single component pilot light with transformer provides clear visual feedback on the status of your machines. It is easily installed into a standard 30mm diameter panel cut-outs and connected with simple screw-clamp connections. It is clearly distinguishable visually at a distance due to clear colors and illumination via integral LED, enabling complex machine statuses to be read at a glance. It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP66, making it ideal for operation in harsh environments. Impact and corrosion resistant metal bezel and body ensures product continues to operate even after severe accidents.
Additional Information
Device Presentation:
complete product
Operating Mode:
normal
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
[Us] Rated Supply Voltage:
110...120 V AC
Environmental Disclosure:
ENVPEP121006EN
Circularity Profile:
N/A
Lens Type:
fresnel plastic
Mounting Diameter:
30 mm
Product Certifications:
CE || CSA LR25490 class 3211 03 || UL listed file E42259 CCN NKCR
Light Source:
incandescent bulb
Connections - Terminals:
screw clamp terminals, 1 x 0.22...2 x 1.5 mm² IEC 60947-1
Light Source:
incandescent
China Rohs Regulation:
X
[Us] Rated Supply Voltage:
110...120 V
California Proposition 65:
WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Bulb Base:
BA 9s
Mercury Free:
Yes
Eu Rohs Directive:
Pro-active compliance (Product out of EU RoHS legal scope)
Weee:
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Range Of Product:
Harmony 9001K
Product Or Component Type:
pilot light
Supply Frequency:
50...60 Hz
Nema Degree Of Protection:
NEMA 1/2/3/3R/4/6/12/13
Rohs Exemption Information:
Yes
Light Block Supply:
via transformer 120 V AC 50/60 Hz || via integral transformer 110 V AC 50/60 Hz
Lens Type:
fresnel
Lens Material:
polycarbonate
Warranty:
18 months
Operating Position:
any position
Sustainable Offer Status:
Green Premium product
Light Block Supply:
via integral transformer
Size:
30 mm
Shape Of Screw Head:
round
Device Short Name:
K
Cap/Operator Or Lens Colour:
amber
Bezel Material:
metal
Brochure:
View
Datasheet:
View
