Schneider Electric 9001KP38LGG6 Pilot Light 120V 30Mm Type K +Options
This Harmony 9001K, green pilot light with integral LED and glass dome is supplied with 110V AC/DC. It has a chromium-plated metal bezel. This single component pilot light provides clear visual feedback on the status of your machines. It is easily installed into a standard 30mm diameter panel cut-outs and connected with simple screw-clamp connections. It is clearly distinguishable visually at a distance due to clear colors and illumination via integral LED, enabling complex machine statuses to be read at a glance. It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP66, making it ideal for operation in harsh environments. Impact and corrosion resistant metal bezel and body ensures product continues to operate even after severe accidents.
- [Ui] Rated Insulation Voltage:
- 250 V 2)IEC 60947-1
- [Us] Rated Supply Voltage:
- 120 V
- Shape Of Screw Head:
- cross slotted
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Product Or Component Type:
- pilot light
- Device Short Name:
- 9001K
- Device Presentation:
- complete product
- Nema Degree Of Protection:
- NEMA 1 || NEMA 12 || NEMA 13 || NEMA 2 || NEMA 3 || NEMA 3R || NEMA 4 || NEMA 6
- Product Certifications:
- NEMA || UL 508
- Lens Type:
- domed
- Standards:
- EN/IEC 60947-1 || JIS C8201-5-1 || EN/IEC 60947-5-4 || JIS C 852 || EN/IEC 60947-5-1 || UL 508 || CSA C22.2 No 14 || JIS C8201-1
- Cad Overall Width:
- 54 mm
- Warranty:
- 18 months
- Light Source Colour:
- green
- Vibration Resistance:
- 7 gn 2-500 Hz)IEC 60068-2-6
- [Uimp] Rated Impulse Withstand Voltage:
- 2.5 kV IEC 60947-1
- [Ith] Conventional Free Air Thermal Current:
- 0.416666666666667
- Light Source:
- Green LED
- Short-Circuit Protection:
- 10 A cartridge fuse IEC 60947-5-1
- Ambient Air Temperature For Operation:
- -25-70 °C
- Weee:
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Size:
- 30 mm
- Cad Overall Depth:
- 42 mm
- Light Source:
- LED
- Connections - Terminals:
- screw clamp terminals, 1 x 0.22...2 x 1.5 mm² IEC 60947-1
- Tightening Torque:
- 0.8-0.8 N.m IEC 60947-1
- Environmental Disclosure:
- ENVPEP121006EN
- Ambient Air Temperature For Storage:
- -40-70 °C
- Sustainable Offer Status:
- Green Premium product
- Shock Resistance:
- 50 gn IEC 60068-2-27
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- Lens Material:
- glass
- Bulb Base:
- BA 9s
- [Us] Rated Supply Voltage:
- 120 V AC/DC
- China Rohs Regulation:
- X
- Mounting Diameter:
- 30 mm
- Net Weight:
- 0.134 kg
- Range Of Product:
- Harmony 9001K
- Protective Treatment:
- TC
- Rohs Exemption Information:
- Yes
- Light Block Supply:
- direct 120 V AC/DC
- Shape Of Signaling Unit Head:
- round
- Lens Type:
- domed glass
- Cad Overall Height:
- 70 mm
- Mercury Free:
- Yes
- Cap/Operator Or Lens Colour:
- green
- Operating Position:
- any position
- Circularity Profile:
- N/A
- Ip Degree Of Protection:
- IP66 IEC 60529
- Overvoltage Category:
- class II IEC 61140
- Bezel Material:
- metal
