Schneider Electric 9001KQ13B 30Mm Selector Push Button
Schneider Electric
$81.00
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
The 9001K push button line has a large variety of operators and accessories for heavy industry applications. These operators are used in the petrochemical, metallurgy, mining, oil and gas, wastewater treatment and automotive manufacturing industries and more. Type K operators have a die cast operator that mounts in a 1.18 inch round hole. This operator combines the function of a momentary push button and a two position selector switch into one operator. Operator is supplied with a black insert. Two 9001KA1 contact blocks must be added to this operator to make it work properly. When properly installed this opertor is UL listed for Types 1, 2, 3, 3R, 4, 6, 12 and 13 environments. This operator is UL Listed and CSA certified. "It is ideal for petrochemical, metallurgy, mining, oil and gas applications. It is also suitable for automotive, water and wastewater treatment applications." "This product meets EN 60947-5-1/A1 standard." "It is installed into a 30mm panel cutout." "A comprehensive range of illuminated pushbuttons, pilot lights, emergency stop buttons, selector switches, joystick controllers and accessories to fit your needs." "The modular range of 30mm metal control and signaling provides robust and reliable solutions for a wide range of heavy industry applications."
- Warranty:
- 18 months
- Sustainable Offer Status:
- Green Premium product
- Device Short Name:
- 9001K
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- Operator Position Information:
- 2 positions
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Rohs Exemption Information:
- Yes
- Sale Per Indivisible Quantity:
- 1
- Mercury Free:
- Yes
- Range Of Product:
- Harmony 9001K
- Product Or Component Type:
- push-button switch
- Environmental Disclosure:
- ENVPEP121006EN
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- China Rohs Regulation:
- X
- Circularity Profile:
- N/A
- Mounting Diameter:
- 30 mm
- Bezel Material:
- metal
- Weee:
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
- Brochure:
- View
- Catalog:
- View
- Datasheet:
- View
