Schneider Electric 9001SKP38LWW9 White Led Pilot Light 120V 30Mm T-Skp

(No reviews yet) Write a Review

Write a Review

Schneider Electric 9001SKP38LWW9 White Led Pilot Light 120V 30Mm T-Skp

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

9001SKP38LWW9

UPC:

3.38912E+12

MPN:

Condition:

New

Light Source Colour:

white

Net Weight:

0.082 kg

Device Presentation:

complete product

Bezel Material:

plastic

Product Certifications:

UL 508 || NEMA

Connections - Terminals:

screw clamp terminals, 1 x 0.22...2 x 1.5 mm² EN/IEC 60947-1

Toxic Heavy Metal Free:

Yes

Ambient Air Temperature For Operation:

-25-70 °C

China Rohs Regulation:

X

Operating Position:

any position

Shock Resistance:

50 gn IEC 60068-2-27

Tightening Torque:

0.8-0.8 N.m EN/IEC 60947-1

Nema Degree Of Protection:

NEMA 1 || NEMA 12 || NEMA 13 || NEMA 2 || NEMA 3 || NEMA 3R || NEMA 4 || NEMA 4X

[Us] Rated Supply Voltage:

120 V

Cad Overall Depth:

42 mm

Ambient Air Temperature For Storage:

-40-70 °C

Bulb Base:

BA 9s

Shape Of Signaling Unit Head:

round

Lens Material:

polycarbonate

Standards:

UL 508 || JIS C 852 || EN/IEC 60947-5-4 || JIS C8201-5-1 || EN/IEC 60947-1 || CSA C22.2 No 14 || EN/IEC 60947-5-1 || JIS C8201-1

Rohs Exemption Information:

Yes

Environmental Disclosure:

ENVPEP1710019EN

Shape Of Screw Head:

cross slotted

[Uimp] Rated Impulse Withstand Voltage:

2.5 kV EN/IEC 60947-1

Short-Circuit Protection:

10 A cartridge fuse EN/IEC 60947-5-1

Cap/Operator Or Lens Colour:

white

Ip Degree Of Protection:

IP66 IEC 60529

Product Or Component Type:

pilot light

Light Source:

LED

Circularity Profile:

ENVEOLI1710019EN

Device Short Name:

9001SK

Cad Overall Width:

54 mm

Reach Free Of Svhc:

Yes

Protective Treatment:

TC

Weee:

The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.

[Ui] Rated Insulation Voltage:

250 V 2)EN/IEC 60947-1

Size:

30 mm

[Ith] Conventional Free Air Thermal Current:

0.416666666666667

Eu Rohs Directive:

Pro-active compliance (Product out of EU RoHS legal scope)

California Proposition 65:

WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Cad Overall Height:

70 mm

Warranty:

18 months

Vibration Resistance:

7 gn 2-500 Hz)IEC 60068-2-6

Lens Type:

domed plastic

Mounting Diameter:

30 mm

Electrical Shock Protection Class:

class II IEC 61140

Reach Regulation:

Free of Substances of Very High Concern above the threshold

Mercury Free:

Yes

Range Of Product:

Harmony 9001SK

Sustainable Offer Status:

Green Premium product

Light Block Supply:

direct 120 V AC/DC

[Us] Rated Supply Voltage:

120 V AC/DC

Lens Type:

domed

Brochure:

View

Datasheet:

View
