Schneider Electric 9001SKS11FB Selector Switch Operator 30Mm Sk

(No reviews yet) Write a Review

Write a Review

Schneider Electric 9001SKS11FB Selector Switch Operator 30Mm Sk

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

9001SKS11FB

UPC:

3.38912E+12

MPN:

Condition:

New

Net Weight:

0.059 kg

Vibration Resistance:

7 gn 2-500 Hz)IEC 60068-2-6

California Proposition 65:

WARNING: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other repr

Mercury Free:

Yes

Toxic Heavy Metal Free:

Yes

China Rohs Regulation:

X

Environmental Disclosure:

ENVPEP120820EN

Reach Free Of Svhc:

Yes

Shock Resistance:

50 gn IEC 60068-2-27

Reach Regulation:

Free of Substances of Very High Concern above the threshold

Operator Profile:

black long handle

Device Presentation:

basic element

Ambient Air Temperature For Storage:

-40-70 °C

Contacts Type And Composition:

without contact block

Range Of Product:

Harmony 9001SK

Bezel Material:

plastic

Circularity Profile:

N/A

Nema Degree Of Protection:

NEMA 1 || NEMA 12 || NEMA 13 || NEMA 2 || NEMA 3 || NEMA 3R || NEMA 4 || NEMA 4X || NEMA 6

Mechanical Durability:

500000 cycles

Protective Treatment:

TC

Ambient Air Temperature For Operation:

-25-70 °C

Shape Of Signaling Unit Head:

octagonal

Rohs Exemption Information:

Yes

Cap/Operator Or Lens Colour:

black

Mounting Diameter:

30 mm

Standards:

CSA C22.2 No 14 || JIS C 4520 || EN/IEC 60947-5-4 || UL 508 || EN/IEC 60947-1 || JIS C 852 || EN/IEC 60947-5-1

Product Compatibility:

9001KA2 side 1 or 2

Eu Rohs Directive:

Pro-active compliance (Product out of EU RoHS legal scope)

Operator Profile:

long handle

Product Certifications:

NEMA || UL 508

Operator Position Information:

2 positions

Electrical Shock Protection Class:

class II IEC 61140

Cam Profile:

5

Device Short Name:

9001SK

Size:

30 mm

Weee:

The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.

Sustainable Offer Status:

Green Premium product

Product Or Component Type:

head for selector switch

Warranty:

18 months

Ip Degree Of Protection:

IP66 IEC 60529

Brochure:

View

Datasheet:

View
