Schneider Electric 9001SKT7R31 Pilot Light 240Vac 30Mm Sk +Options
SKU:
9001SKT7R31
UPC:
785901348085
MPN:
Condition:
New
Cad Overall Height:
70 mm
[Us] Rated Supply Voltage:
220...240 V AC 50/60 Hz
Shape Of Signaling Unit Head:
round
Light Source:
incandescent bulb
Product Or Component Type:
push-to-test pilot light
Shock Resistance:
50 gn IEC 60068-2-27
Light Block Supply:
via integral transformer 220...240 V AC 50/60 Hz 6 V)
Ip Degree Of Protection:
IP66 IEC 60529
Reach Regulation:
Free of Substances of Very High Concern above the threshold
Ambient Air Temperature For Storage:
-40-70 °C
Cad Overall Depth:
42 mm
Vibration Resistance:
7 gn 2-500 Hz)IEC 60068-2-6
[Ith] Conventional Free Air Thermal Current:
0.416666666666667
Circularity Profile:
ENVEOLI121107EN
[Uimp] Rated Impulse Withstand Voltage:
2.5 kV EN/IEC 60947-1
Cad Overall Width:
54 mm
Eu Rohs Directive:
Pro-active compliance (Product out of EU RoHS legal scope)
Bulb Base:
BA 9s
Lens Type:
fresnel
Ambient Air Temperature For Operation:
-25-70 °C
Rohs Exemption Information:
Yes
Size:
30 mm
Warranty:
18 months
Shape Of Screw Head:
cross slotted
Cap/Operator Or Lens Colour:
red
Lens Type:
fresnel plastic
Operating Position:
any position
Net Weight:
0.181 kg
Environmental Disclosure:
ENVPEP121111EN
Toxic Heavy Metal Free:
Yes
Connections - Terminals:
screw clamp terminals, 1 x 0.22...2 x 1.5 mm² EN/IEC 60947-1
Mounting Diameter:
30 mm
Protective Treatment:
TC
Light Block Supply:
via integral transformer
Bezel Material:
plastic
[Ui] Rated Insulation Voltage:
250 V 2)EN/IEC 60947-1
Mercury Free:
Yes
Tightening Torque:
0.8-0.8 N.m EN/IEC 60947-1
Reach Free Of Svhc:
Yes
Electrical Shock Protection Class:
class II IEC 61140
Contacts Type And Composition:
1 C/O
[Us] Rated Supply Voltage:
220...240 V
Short-Circuit Protection:
10 A cartridge fuse EN/IEC 60947-5-1
California Proposition 65:
WARNING: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other repr
Nema Degree Of Protection:
NEMA 1 || NEMA 12 || NEMA 13 || NEMA 2 || NEMA 3 || NEMA 3R || NEMA 4 || NEMA 4X
Light Source:
incandescent
Device Short Name:
9001SK
China Rohs Regulation:
X
Sustainable Offer Status:
Green Premium product
Operating Mode:
push-to-test
Lens Material:
polycarbonate
Standards:
EN/IEC 60947-5-4 || UL 508 || CSA C22.2 No 14 || EN/IEC 60947-1 || JIS C8201-5-1 || EN/IEC 60947-5-1 || JIS C 852 || JIS C8201-1
Product Certifications:
UL 508 || NEMA
Weee:
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
