Schneider Electric 9050JCK12V20 Timer Relay 240Vac 10Amp +Options
Schneider Electric
$78.00
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
9050JCK plug in timers are designed to provide low cost timing in a plug in housing. This timer has an on delay timing mode. When the input voltage is applied, the time delay begins. Relay contacts change state after time delay is complete. When the input voltage is removed, contacts return to their shelf state. The timing range of 0.3 to 30 seconds is easily adjustable with a knob on the top of the timer. This plug in timer plugs into an 8501NR51 or 8501NR52 relay socket. These relay sockets can be mounted on 35 mm DIN 3 mounting track or directly to a panel. All wiring is made to the relay socket. The DPDT contacts are rated 10 amperes resistive at 120 VAC, 240 VAC and 30 VDC, 3 amperes inductive at 120 VAC, 240 VAC and 30 VDC, 1/3 HP on the NC contacts at 120 VAC and 240 VAC, 1/2 HP on the NO contacts at 120 VAC and 240 VAC. This plug in timer is powered up with 120 VAC / 110 VDC. 9050JCK plug in timers are UL listed when the proper 8501NR relay socket is used, UL component recognized and CSA certified.
- Hold-In Power Consumption In Va:
- 2-2 VA
- Mercury Free:
- Yes
- Maximum Switching Voltage:
- 240 V AC
- Ambient Air Temperature For Operation:
- -18-150 °F
- Width:
- 43 mm
- [Uc] Control Circuit Voltage:
- 120 V AC || 110 V DC
- Time Delay Range:
- 0.3...30 s
- Product Or Component Type:
- timer
- Contacts Material:
- silver nickel
- Line Rated Current:
- 0.416666666666667
- Contacts Type And Composition:
- 2 NO + 2 NC
- Shape Of Pin:
- tubular
- Rohs Exemption Information:
- Yes
- Switch Function:
- DPDT
- Depth:
- 104 mm
- Sustainable Offer Status:
- Green Premium product
- Toxic Heavy Metal Free:
- Yes
- Pin Number:
- 8
- Time Delay Type:
- on-delay
- Product Certifications:
- UL Recognized || UL Listed || CE
- Environmental Disclosure:
- ENVPEP1406037EN
- Reach Free Of Svhc:
- Yes
- Circularity Profile:
- ENVEOLI1406037EN
- Product Compatibility:
- 8501NR51 || 8501NR52
- China Rohs Regulation:
- X
- Reach Regulation:
- Free of Substances of Very High Concern above the threshold
- Mounting Support:
- socket
- Warranty:
- 18 months
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Range Of Product:
- 9050JCK
- Height:
- 61 mm
