Schneider Electric 9AS3A24 Electromechnical Power Relays, 24Vac Pack of 10

Schneider Electric 9AS3A24 Electromechnical Power Relays, 24Vac Pack of 10

Schneider Electric
SKU:
9AS3A24
|
UPC:
3606489915254
$128.90
(No reviews yet) Write a Review
Condition:
New
Current Stock:
Description
Electromechnical Power Relays, Harmony 9A, 30A, 24 VAC SPST-NO, flanged panel mount, sealed cover
Additional Information
Maximum Switching Voltage:
277 V AC || 28 V DC
Rated Power In Va:
470 VA at 240 V on pilot duty
Eu Rohs Directive:
Compliant
Sustainable Offer Status:
Green Premium product
Shock Resistance:
10 gn operating || 100 gn not operating
Reset Time:
10 ms
Protection Category:
RT III
Lead Free:
Yes
[Uimp] Rated Impulse Withstand Voltage:
4 kV 1.2/50 µs
Width:
27.3 mm
Pvc Free:
Yes
Average Resistance:
100 Ohm at 23 °C +/- 10 %
Contacts Type And Composition:
NO
Dielectric Strength:
2500 V AC between coil and contact || 1500 V between contacts with micro disconnection
Vibration Resistance:
+/- 0.75 mm 10-55 Hz operating || +/- 0.75 mm 10-55 Hz not operating
Rated Power In Hp:
1 hp at 125 V AC || 2 hp at 250 V AC
Contacts Material:
silver alloy contacts
Silicon Free:
Yes
Environmental Disclosure:
ENVPEP2006003EN
[Uc] Control Circuit Voltage:
24 V AC 50-60 Hz
Reach Regulation:
Free of Substances of Very High Concern above the threshold
Range Of Product:
Harmony
Depth:
27.8 mm
Net Weight:
0.032 kg
Ambient Air Temperature For Storage:
-40-85 °C
Control Circuit Voltage Limits:
0.85...1.1 Uc
Weee:
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Reach Free Of Svhc:
Yes
China Rohs Regulation:
X
Ambient Air Temperature For Operation:
-40-40 °C
Network Frequency:
50-60 Hz
Minimum Switching Capacity:
5 W at 1 A, 5 V DC || 12 VA at 1 A, 12 V AC
Pollution Degree:
3
California Proposition 65:
WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Mounting Support:
panel flange
Product Certifications:
UL
Mechanical Durability:
10000000 cycles
Average Consumption:
2.6 VA
Switch Function:
SPST
Operating Position:
any position
Drop-Out Voltage Threshold:
>= 0.2 Uc
Rohs Exemption Information:
Yes
Circularity Profile:
ENVEOLI2006003EN
Connections - Terminals:
Faston terminals contact terminal AWG 12...AWG 10, connection size: 6.35 x 0.8 mm || Faston terminals coil terminal AWG 22...AWG 14, connection size: 4.8 x 0.5 mm
Phenolic Free Solution:
Yes
Product Or Component Type:
power relay
Toxic Heavy Metal Free:
Yes
[Ui] Rated Insulation Voltage:
320 V
Mercury Free:
Yes
Standards:
UL 60947-4-1
Operating Time:
20 ms
Input Current:
30 A
Height:
50 mm
Electrical Durability:
100000 cycles, 30 A at 240 V, AC-1 || 50000 cycles for resistive load, 30 A at 28 V, DC || 100000 cycles for resistive load, 24 A at 240 V, AC || 30000 cycles for full load, 22 A at 120 V, AC-8a || 1000 cycles for motor load || 6000 cycles for ballas
[Ie] Rated Operational Current:
30 A at 240 V AC-1 || 30 A at 28 V DC (on resistive load) || 24 A at 240 V AC (on resistive load) || 98 A at 120 V AC-8a (locked rotor) || 22 A at 120 V AC-8a (full load) || 10 A at 277 V AC-5a (ballast)
