Schneider Electric A9XPCM04 Acti9 Set Of 4 Connectors Monocon
Schneider Electric
$127.59
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
This Acti9 Linergy FH monoconnect connector for Acti9 iC60 and Acti9 iK60 facilitates comb busbar power supply. It is a set of 4 devices. The Type of electric connection is PIN. The pin cross section is 16mm2. The cross section of the cable connector is 35mm2. The tightening torque is 4N.m. The color of the device is white RAL9003. The pollution degree is 3. It complies with IEC 60947-7-1 and IEC 61439-2 standards.
- Circularity Profile:
- N/A
- Product Or Component Type:
- connector
- Weee:
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
- Environmental Disclosure:
- ENVPEP2005011
- Quantity Per Set:
- set of 4
- China Rohs Regulation:
- Product out of China RoHS scope. Substance declaration for your information.
- Connections - Terminals:
- screw clamp terminals top connector 35-35 mm²
- Product Name:
- Linergy FH
- Comb Busbar And Distribution Block Compatibility:
- monoconnect
- Rohs Exemption Information:
- Yes
- Accessory / Separate Part Category:
- connection accessory
- Reach Free Of Svhc:
- Yes
- Sustainable Offer Status:
- Green Premium product
- Reach Regulation:
- Free of Substances of Very High Concern above the threshold
- Line Rated Current:
- 100 A
- Warranty:
- 18 months
- Mercury Free:
- Yes
- Poles Description:
- 3P + N
- Tightening Torque:
- 4-4 N.m
- Eu Rohs Directive:
- Compliant with Exemptions
- Range Compatibility:
- Acti 9 Acti9 iC60 comb busbar || Acti 9 Acti9 iK60 comb busbar || Acti 9 Acti9 iDPN comb busbar || Acti 9 Acti9 iDPN Vigi comb busbar || Acti 9 Acti9 iID comb busbar || Acti 9 Acti9 iID K comb busbar || Acti 9 Acti9 iSW comb busbar || Acti 9 Acti9 iS
- Range:
- Acti9
- Color:
- White RAL 9003)
- Brochure:
- View
- Catalog:
- View
- Datasheet:
- View
