Schneider Electric ABE7CPA412 Wiring Block For 4 Tc Inputs

Schneider Electric ABE7CPA412 Wiring Block For 4 Tc Inputs

Schneider Electric
SKU:
ABE7CPA412
|
UPC:
3595863914696
Availability:
Contact us to confirm availability and lead times.
$440.00
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
This connection sub-base is part of the Modicon ABE7 range, an offer of IP20 sub-bases for Telefast pre-wired system. It is for distribution of 4 thermocouples. It distributes isolated sensor power supplies by means of a converter. It supplies cold-junction compensation for the connected thermocouple input. It is furnished with screw type terminals for electrical connection and 25-way SUB-D connection to Programmable Logic Controllers (PLC). It is an IP20 rated product. It weighs 0.18kg. It is suitable for all types of industrial applications. This product is certified by LROS, DNV, UL, GL, BV and CSA. This connection sub-base is suitable for use with Modicon M340 BMXART0414 analog input module and Modicon M340 BMXART0814 analog input module. It is delivered in 2 packages (PCE and SO3 types). It can be fixed by clips (35mm symmetrical DIN rail) and screws (solid plate with fixing kit). Modicon ABE7 means greater simplicity to rationalise wiring in automation system equipment.
Additional Information
Vibration Resistance:
2 gn 10-150 Hz)IEC 60068-2-6
Eu Rohs Directive:
Pro-active compliance (Product out of EU RoHS legal scope)
Resistance To Incandescent Wire:
750 °C 30 s IEC 60695-2-11
China Rohs Regulation:
X
Fixing Mode:
by clips 35 mm symmetrical DIN rail) || by screws solid plate with fixing kit)
Ambient Air Temperature For Storage:
-40-80 °C IEC 61131-2
Warranty:
18 months
Ip Degree Of Protection:
IP20 conforming to IEC 60529
Range Of Product:
Modicon ABE7
Pollution Degree:
2 IEC 60664-1
Resistance To Electrostatic Discharge:
4 kV contact) level 3 IEC 61000-4-2 || 8 kV air) level 3 IEC 61000-4-2
Ambient Air Temperature For Operation:
0-60 °C IEC 61131-2
Number Of Channels:
4
Shock Resistance:
15 gn 11 ms IEC 60068-2-27
Mercury Free:
Yes
[Ui] Rated Insulation Voltage:
2000 V terminals/mounting rails
Resistance To Fast Transients:
2 kV level 3 IEC 61000-4-4
Resistance To Radiated Fields:
10 V/m 26000000-1000000000 Hz)IEC 61000-4-3 level 3
Installation Category:
II IEC 60664-1
Product Certifications:
GL || CSA || UL || DNV
Net Weight:
0.18 kg
Product Compatibility:
Modicon M340 BMXART0414 || Modicon M340 BMXART0814
Product Or Component Type:
connection sub-base for analogue channels
Connections - Terminals:
screw type terminals, 1 x 0.09...1 x 1.5 mm² AWG 28...AWG 16) flexible with cable end || screw type terminals, 1 x 0.14...1 x 2.5 mm² AWG 26...AWG 12) solid || screw type terminals, 1 x 0.14...1 x 2.5 mm² AWG 26...AWG 14) flexible without cable en
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Function Of Module:
distribution of 4 thermocouples Modicon M340
Connection To Plc:
SUB-D 25
Rohs Exemption Information:
Yes
Tightening Torque:
0.6 N.m flat Ø 3.5 mm
California Proposition 65:
WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
