Schneider Electric ATV12H037M2TQ Atv12 0.37Kw 240V 1Ph Heat Sink Tb Pack of 14

(No reviews yet) Write a Review

Write a Review

Schneider Electric

Schneider Electric ATV12H037M2TQ Atv12 0.37Kw 240V 1Ph Heat Sink Tb Pack of 14

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

ATV12H037M2TQ

UPC:

3.60648E+12

MPN:

Condition:

New

Mounting Mode:

cabinet mount

Product Specific Application:

simple machine

Operating Altitude:

> 3280.84...6561.68 ft (> 1000...2000 m) with current derating 1 % per 100 m || <= 3280.84 ft (1000 m) without derating

Protection Type:

line supply overvoltage || line supply undervoltage || overcurrent between output phases and earth || overheating protection || short-circuit between motor phases || against input phase loss in three-phase || thermal motor protection via the drive by

Method Of Access:

server Modbus serial

Maximum Output Voltage:

240 V

With Safety Function Safe Direction (Sdi):

FALSE

4 Quadrant Operation Possible:

FALSE

Nominal Switching Frequency:

4 kHz

With Safety Function Safe Brake Management (Sbc/Sbt):

FALSE

Standards:

UL 508C || UL 618000-5-1 || IEC 61800-5-1 || IEC 61800-3

Weee:

The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.

Operating Position:

vertical +/- 10 degree

Insulation:

electrical between power and control

Network Frequency:

50-60 Hz

Regulation Loop:

adjustable PID regulator

California Proposition 65:

WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Number Of Addresses:

1-247

Maximum Output Frequency:

4 kHz

Nominal Output Current:

2.4 A

Ambient Air Temperature For Storage:

-25-70 °C

With Safety Function Safe Programmable Logic:

FALSE

Maximum Acceleration Under Vibrational Stress (During Operation):

10 m/s² at 13...200 Hz

Overvoltage Category:

class III

Linearity Error:

+/- 0.3 % of maximum value analogue input

Relative Symmetric Network Frequency Tolerance:

0.05

Relay Output Number:

1

Electromagnetic Compatibility:

electrical fast transient/burst immunity test level 4 IEC 61000-4-4 || electrostatic discharge immunity test level 3 IEC 61000-4-2 || immunity to conducted disturbances level 3 IEC 61000-4-6 || radiated radio-frequency electromagnetic field immunity

With Safety Function Safe Operating Stop (Sos):

FALSE

Range Of Product:

Altivar 12

Data Format:

8 bits, configurable odd, even or no parity

Tightening Torque:

0.8 N.m

Brake Chopper Integrated:

FALSE

Maximum Deflection Under Vibratory Load (During Operation):

1.5 mm at 2...13 Hz

Speed Range:

45311

With Safety Function Safe Stop 1 (Ss1):

FALSE

Noise Level:

0 dB

Power Dissipation In W:

natural 27.0 W

With Safety Function Safe Position (Sp):

FALSE

Relative Humidity:

5-95 % without condensation IEC 60068-2-3 || 5-95 % without dripping water IEC 60068-2-3

Environmental Class (During Operation):

class 3C3 according to IEC 60721-3-3 || class 3S2 according to IEC 60721-3-3

Net Weight:

0.7 kg

Electromagnetic Emission:

radiated emissions environment 1 category C2 IEC 61800-3 2...16 kHz shielded motor cable || conducted emissions with integrated EMC filter environment 1 category C1 IEC 61800-3 2, 4, 8, 12 and 16 kHz shielded motor cable <5 m || conducted emissions w

Communication Port Protocol:

Modbus

Motor Slip Compensation:

preset in factory || adjustable

Product Or Component Type:

variable speed drive

Shock Resistance:

15 gn 11 ms IEC 60068-2-27

[Us] Rated Supply Voltage:

200...240 V - 15...10 %

Supply Frequency:

50/60 Hz +/- 5 %

Continuous Output Current:

2.4 A 4 kHz

Emc Filter:

integrated

Height:

143 mm

Base Load Current At High Overload:

2.4 A

Marking:

CE

Discrete Input Number:

4

With Safety Function Safely Limited Position (Slp):

FALSE

Communication Service:

read holding registers (03) 29 words || write single register (06) 29 words || write multiple registers (16) 27 words || read/write multiple registers (23) 4/4 words || read device identification (43)

With Safety Function Safe Torque Off (Sto):

FALSE

Depth:

121.2 mm

Prospective Line Isc:

1 kA

Asynchronous Motor Control Profile:

quadratic voltage/frequency ratio || voltage/frequency ratio (V/f) || sensorless flux vector control

Speed Drive Output Frequency:

0.5-400 Hz

Analogue Input Number:

1

Analogue Output Number:

1

Maximum Acceleration Under Shock Impact (During Operation):

150 m/s² at 11 ms

With Safety Function Safe Speed Monitor (Ssm):

FALSE

Line Current:

5.9 A 100 V heavy duty) || 4.9 A 120 V heavy duty)

Motor Power Kw:

0.37 kW

Ambient Air Transport Temperature:

-25-70 °C

Sampling Duration:

20 ms +/- 1 ms logic input || 10 ms analogue input

Mercury Free:

Yes

With Sft Fct Safe Stop 2 (Ss2):

FALSE

Vibration Resistance:

1 gn 13-200 Hz)IEC 60068-2-6 || 1.5 mm peak to peak 3-13 Hz) - drive unmounted on symmetrical DIN rail - IEC 60068-2-6

Switching Frequency:

2...16 kHz adjustable || 4...16 kHz with derating factor

Transmission Frame:

RTU

Frequency Resolution:

analog input converter A/D, 10 bits || display unit 0.1 Hz

Quantity Per Set:

set of 14

Transmission Rate:

9.6 kbit/s || 19.2 kbit/s || 38.4 kbit/s

Discrete Output Number:

2

Pollution Degree:

2

Time Constant:

20 ms +/- 1 ms for reference change

Acceleration And Deceleration Ramps:

U || linear from 0 to 999.9 s || S

Type Of Polarization:

no impedance

Rohs Exemption Information:

Yes

Ip Degree Of Protection:

IP20

Warranty:

18 months

Reach Regulation:

Reference contains Substances of Very High Concern above the threshold

With Safety Function Safely Limited Speed (Sls):

FALSE

Product Certifications:

NOM || CSA || C-tick || UL || GOST || RCM || KC

China Rohs Regulation:

X

Transient Overtorque:

150-170 % of nominal motor torque depending on drive rating and type of motor

Assembly Style:

with heat sink

Ambient Air Temperature For Operation:

-10-40 °C without derating || 40-60 °C with current derating 2.2 % per °C

Connector Type:

1 RJ45

Apparent Power:

1.2 kVA 240 V heavy duty)

Braking To Standstill:

by DC injection

Maximum Transient Current:

3.6 A 60 s heavy duty) || 4.0 A 2 s heavy duty)

Eu Rohs Directive:

Pro-active compliance (Product out of EU RoHS legal scope)

Maximum Horse Power Rating:

0.55 hp

Width:

72 mm

Physical Interface:

2-wire RS 485
