Schneider Electric ATV950D75N4U Atv950 Ip55 Ultype12 75Kw 400V/480V Vari
SKU:
ATV950D75N4U
UPC:
3.60648E+12
MPN:
Condition:
New
Variant:
with braking chopper || standard version
Exchange Mode:
half duplex, full duplex, autonegotiation Ethernet IP/Modbus TCP
Electromagnetic Compatibility:
electrostatic discharge immunity test level 3 IEC 61000-4-2 || radiated radio-frequency electromagnetic field immunity test level 3 IEC 61000-4-3 || electrical fast transient/burst immunity test level 4 IEC 61000-4-4 || 1.2/50 µs - 8/20 µs surge im
Circularity Profile:
ENVEOLI1506002EN
Discrete Input Logic:
16 preset speeds
Marking:
CE
Analogue Output Number:
2
Environmental Disclosure:
ENVPEP1506002EN
Overvoltage Category:
III
Ambient Air Transport Temperature:
-40-70 °C
Ambient Air Temperature For Operation:
-15-40 °C without derating) || 40-50 °C with derating factor)
Shock Resistance:
15 gn 11 ms IEC 60068-2-27
Environmental Class (During Operation):
class 3C3 according to IEC 60721-3-3 || class 3S3 according to IEC 60721-3-3
Relative Symmetric Network Frequency Tolerance:
0.05
Line Current:
131.3 A 380 V normal duty) || 98.9 A 380 V heavy duty) || 112.7 A 480 V normal duty) || 86.9 A 480 V heavy duty)
Motor Slip Compensation:
not available in permanent magnet motor law || automatic whatever the load || adjustable || can be suppressed
Maximum Switching Current:
relay output R1 resistive, cos phi = 1 3 A 250 V AC || relay output R1 resistive, cos phi = 1 3 A 30 V DC || relay output R1 inductive, cos phi = 0.4 7 ms 2 A 250 V AC || relay output R1 inductive, cos phi = 0.4 7 ms 2 A 30 V DC || relay output R2, R
Permitted Relative Humidity (During Operation):
class 3K5 according to EN 60721-3
Maximum Deflection Under Vibratory Load (During Operation):
1.5 mm at 2...13 Hz
Weee:
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Connector Type:
2 RJ45 || 1 RJ45
Ip Degree Of Protection:
IP55
Noise Level:
69.9 dB 86/188/EEC
Phase:
3 phase
Local Signalling:
local diagnostic 3 LED mono/dual colour) || embedded communication status 5 LED dual colour) || communication module status 2 LED dual colour) || presence of voltage 1 LED red)
Method Of Access:
slave Modbus TCP
Product Or Component Type:
variable speed drive
Protection Type:
thermal protection motor || safe torque off motor || motor phase break motor || thermal protection drive || safe torque off drive || overheating drive || overcurrent between output phases and earth drive || overload of output voltage drive || short-c
Pro-active compliance (Product out of EU RoHS legal scope)
Maximum Acceleration Under Shock Impact (During Operation):
150 m/s² at 11 ms
Environmental Characteristic:
chemical pollution resistance class 3C3 IEC 60721-3-3 || dust pollution resistance class 3S3 IEC 60721-3-3
Maximum Output Frequency:
599 Hz
Type Of Polarization:
no impedance Modbus serial
Mercury Free:
Yes
Continuous Output Current:
145 A 2.5 kHz normal duty || 106 A 2.5 kHz heavy duty
Number Of Addresses:
1-247
Depth:
375 mm
Insulation Resistance:
> 1 MOhm 500 V DC for 1 minute to earth
Discrete Input Type:
DI1...DI8 programmable, 24 V DC <= 30 V)3.5 kOhm || DI7, DI8 programmable as pulse input 0-30 kHz, 24 V DC <= 30 V) || STOA, STOB safe torque off, 24 V DC <= 30 V)> 2.2 kOhm
Upgradeability:
Upgraded components available
Regulation Loop:
adjustable PID regulator
Operating Altitude:
<= 3280.84 ft (1000 m) without derating || 1000...4800 m with current derating 1 % per 100 m
Supply:
external supply for digital inputs 24 V DC 19-30 V), <1.25 mA overload and short-circuit protection || internal supply for reference potentiometer (1 to 10 kOhm) 10.5 V DC +/- 5 %, <10 mA overload and short-circuit protection || internal supply for d
Nominal Switching Frequency:
2.5 kHz
Synchronous Motor Control Profile:
permanent magnet motor || synchronous reluctance motor
1...8 kHz adjustable || 2.5...8 kHz with derating factor
Asynchronous Motor Control Profile:
constant torque standard || variable torque standard || optimized torque mode
Isolation:
between power and control terminals
Range Of Product:
Altivar Process ATV900
Degree Of Protection:
UL type 12
With Safety Function Safe Programmable Logic:
FALSE
Height:
1250 mm
Electrical Connection:
control screw terminal 0.5...1.5 mm² AWG 20...AWG 16 || DC bus screw terminal 70...120 mm² AWG 1/0...250 kcmil || motor screw terminal 95...120 mm² AWG 3/0...250 kcmil || line side screw terminal 70...120 mm² AWG 2/0...250 kcmil
Discrete Output Number:
2
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Discrete Input Number:
10
Sampling Duration:
2 ms +/- 0.5 ms DI1...DI8) - discrete input || 5 ms +/- 1 ms DI7, DI8) - pulse input || 1 ms +/- 1 ms AI1, AI2, AI3) - analog input || 5 ms +/- 1 ms AQ1, AQ2) - analog output
Refresh Time:
relay output R1, R2, R3)5 ms +/- 0.5 ms)
Maximum Acceleration Under Vibrational Stress (During Operation):
10 m/s² at 13...200 Hz
Data Format:
8 bits, configurable odd, even or no parity Modbus serial
With Safety Function Safe Brake Management (Sbc/Sbt):
TRUE
Width:
345 mm
With Safety Function Safe Position (Sp):
FALSE
Brake Chopper Integrated:
TRUE
Ambient Air Temperature For Storage:
-40-70 °C
Rohs Exemption Information:
Yes
With Sft Fct Safe Stop 2 (Ss2):
FALSE
Operating Position:
vertical +/- 10 degree
With Safety Function Safe Operating Stop (Sos):
FALSE
Braking To Standstill:
by DC injection
Network Frequency:
50-60 Hz
Physical Interface:
Ethernet || 2-wire RS 485
Analogue Input Number:
3
Maximum Transient Current:
174 A 60 s normal duty) || 159 A 60 s heavy duty)
Pollution Degree:
2
China Rohs Regulation:
X
Communication Port Protocol:
EtherNet/IP || Modbus serial || Modbus TCP
Data Format:
8 bits, configurable odd, even or no parity
Maximum Output Voltage:
480.0 V
With Safety Function Safe Torque Off (Sto):
TRUE
Linearity Error:
AI1, AI2, AI3 +/- 0.15 % of maximum value analog input || AQ1, AQ2 +/- 0.2 % analog output
Relative Humidity:
5-95 % without condensation IEC 60068-2-3
Relay Output Number:
3
Base Load Current At Low Overload:
145.0 A
Analogue Input Type:
AI1, AI2, AI3 software-configurable voltage 0...10 V DC 30 kOhm 12 bits || AI1, AI2, AI3 software-configurable current 0...20 mA/4...20 mA 250 Ohm 12 bits
Motor Power Kw:
75.0 kW normal duty || 55.0 kW heavy duty
Apparent Power:
93.7 kVA 480 V normal duty) || 72.2 kVA 480 V heavy duty)
Analogue Output Type:
software-configurable voltage AQ1, AQ2 0...10 V DC 470 Ohm 10 bits || software-configurable current AQ1, AQ2 0...20 mA 500 Ohm 10 bits
4 Quadrant Operation Possible:
TRUE
Product Certifications:
ABS || DNV-GL || Bureau Veritas || CSA || UL || ATEX INERIS || TÃV
1.5 mm peak to peak 2-13 Hz)IEC 60068-2-6 || 1 gn 13-200 Hz)IEC 60068-2-6
Discrete Output Type:
logic output DQ+ 0-1 kHz <= 30 V DC 100 mA || programmable as pulse output DQ+ 0-30 kHz <= 30 V DC 20 mA || logic output DQ- 0-1 kHz <= 30 V DC 100 mA
Transmission Frame:
RTU
With Safety Function Safely Limited Position (Slp):
FALSE
Mounting Mode:
wall mount
Base Load Current At High Overload:
106.0 A
With Safety Function Safe Direction (Sdi):
FALSE
Prospective Line Isc:
50 kA
Net Weight:
87 kg
Noise Level:
69.9 dB
[Us] Rated Supply Voltage:
380...480 V - 15...10 %
With Safety Function Safe Speed Monitor (Ssm):
FALSE
With Safety Function Safe Stop 1 (Ss1):
TRUE
California Proposition 65:
WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Accuracy:
+/- 0.6 % AI1, AI2, AI3 for a temperature variation 60 °C analog input || +/- 1 % AQ1, AQ2 for a temperature variation 60 °C analog output
slot A communication module Profibus DP V1 || slot A communication module PROFINET || slot A communication module DeviceNet || slot A communication module EtherCAT || slot A communication module CANopen daisy chain RJ45 || slot A communication module
