Schneider Electric BMENOC0301 M580 Ethernet Comm Module
This product is part of the Modicon M580 range, an offer of Programmable Automation Controllers (PAC) and safety Programmable Logic Controllers (PLC) with built-in Ethernet. This communication module has 3 ports. It is integrated with 3 Ethernet RJ45 connectors. Communication services are bandwidth management, FDR server, Modbus TCP I/O scanner and messaging, EtherNet/IP I/O scanner and messaging, embedded 4-port switch, RSTP support, SNMP network administrator, embedded multiport switch etc. It is a communication module with a current consumption of 555mA, works with internal power supply. It is an IP20 rated product. It weighs 0.2kg. It is suitable for medium to large process applications. This product is certified by CE and UL. It meets EN 61131-2, EN 61000-6-4, EN 61000-6-2 and EN 61010-2-201 standards. This connection sub-base is compatible with BMEXBPxxx - Ethernet + X-bus rack. The benefits of Modicon M580 are reduce time to market, improve reliability and sustainability, improve productivity with high performance and increase operating profitability due to improved access to data.
- Current Consumption:
- 900 mA 3.3 V DC for product version >= 13) || 1800 mA 3.3 V DC for product version < 13)
- Communication Service:
- bandwidth management || FDR server || SNMP network administrator || Modbus TCP I/O Scanner and Messaging || Ethernet/IP I/O Scanner and Messaging || RSTP support || port mirroring || embedded multiport switch
- Web Server:
- basic
- Local Signalling:
- for processor running (RUN) 1 LED (green) || for processor or system fault (ERR) 1 LED (red) || for ETH MS (Ethernet port configuration status) 1 LED (green/red) || for Eth NS (Ethernet network status) 1 LED (green/red)
- Concept:
- Transparent Ready
- Port Ethernet:
- 10BASE-T/100BASE-TX
- Ip Degree Of Protection:
- IP20
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Directives:
- 2014/35/EU - low voltage directive || 2014/30/EU - electromagnetic compatibility
- Transmission Support Medium:
- Ethernet backplane
- Range Of Product:
- Modicon M580
- Weee:
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
- Product Compatibility:
- BMEXBP... - Ethernet + X-bus rack
- Rohs Exemption Information:
- Yes
- Product Or Component Type:
- communication module
- Supply:
- internal power supply via rack
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Marking:
- CE
- Mercury Free:
- Yes
- Integrated Connection Type:
- 3 Ethernet RJ45 10/100 Mbit/s double shielded twisted pair
- Net Weight:
- 0.2 kg
- Ambient Air Temperature For Operation:
- 0-60 °C
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- Module Format:
- standard
- China Rohs Regulation:
- X
