Schneider Electric EDB14030EPD Miniature Circuit Breaker 277V 30A

Schneider Electric EDB14030EPD Miniature Circuit Breaker 277V 30A

Schneider Electric
SKU:
EDB14030EPD
|
UPC:
785901475576
Availability:
Contact us to confirm availability and lead times.
$1,151.00
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
E-Frame Breaker are Lighting Panelboard Circuit breakers that are proven effective and reliable which provide a wide variety or robust features that are use specifically in Square D NF Panelboards. This range of breaker is ideally designed to offer superior overload and short circuit protection. All E-Frame breakers have a thermal-magnetic trip unit as well as signal indicator that will indicate when a trip has occur. Mounting bolts are used to hold these breakers in place. This E-Frame breaker is 30A, 1 pole, and has an operating voltage of 277 VAC. It also provides a 25 kA max interrupt rating at 120 VAC. This device has a hold current of 270A which is the maximum current the breaker can be held to ensure it will trip and a trip current of 875A which is the current value when the breaker is guaranteed to trip. Many accessories are available for this breaker. This one includes 30 mA ground protection. This breaker was calibrated for 40 degrees C. This product is UL Listed as High Intensity Discharge. HACR rated.
Additional Information
Net Weight:
2 lb(US)
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Product Destination:
NF panelboard
Earth-Leakage Sensitivity:
30 mA
Tightening Torque:
3.4-3.4 N.m 2.5-16 mm² (AWG 14...AWG 6)
Product Or Component Type:
miniature circuit-breaker
Breaking Capacity Code:
D
Eu Rohs Directive:
Pro-active compliance (Product out of EU RoHS legal scope)
Height:
6.64 in
Mounting Mode:
bolt-on
Holding Current:
270 A
Ambient Air Temperature For Operation:
40 °C
Product Certifications:
cULus || IEC
Awg Gauge:
AWG 14...AWG 6 copper || AWG 12...AWG 4 aluminium
Width:
1.96 in
Number Of Poles:
1
Rohs Exemption Information:
Yes
Number Of Spaces:
2
Trip Unit Rating:
875-875 A
Trip Unit Technology:
thermal-magnetic
Local Signalling:
trip indicator
Number Of Spaces Required:
2
Electrical Connection:
lugs aluminium
Range Of Product:
125 A Frame EDB-EGB-EJB
Breaking Capacity:
18 kA 277 V AC || 18 kA 240 V AC || 25 kA 120 V AC || 18 kA 120/240 V AC
Device Short Name:
EDB
Protection Type:
overload || short-circuit
Module Type:
E-Frame
Earth-Leakage Protection Class:
class B
Line Rated Current:
30 A
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
[Ue] Rated Operational Voltage:
277 V AC
Circuit Breaker Application:
HID rated || HACR rated
Depth:
4.05 in
Mercury Free:
Yes
Warranty:
18 months
