Schneider Electric EGB26070 Miniature Circuit Breaker 600V 70A
Schneider Electric
$1,280.00
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
E-Frame Breaker are Lighting Panelboard Circuit breakers that are proven effective and reliable which provide a wide variety or robust features that are use specifically in Square D NF Panelboards. This range of breaker is ideally designed to offer superior overload and short circuit protection. All E-Frame breakers have a thermal-magnetic trip unit as well as signal indicator that will indicate when a trip has occur. Mounting bolts are used to hold these breakers in place. This E-Frame breaker is 70A, 2 pole, and has an operating voltage of 600Y/347 VAC. It also provides a 65 kA max interrupt rating at 120 VAC. This device has a hold current of 630A which is the maximum current the breaker can be held to ensure it will trip and a trip current of 1800A which is the current value when the breaker is guaranteed to trip. Many accessories are available for this breaker. This breaker was calibrated for 40 degrees C. HACR rated.
- Range Of Product:
- 125 A Frame EDB-EGB-EJB
- Depth:
- 4.05 in
- Net Weight:
- 3 lb(US)
- Number Of Spaces Required:
- 2
- Product Or Component Type:
- circuit-breaker
- Circuit Breaker Application:
- HACR rated
- Electrical Connection:
- lugs aluminium
- Warranty:
- 18 months
- Trip Unit Technology:
- thermal-magnetic
- Number Of Spaces:
- 2
- Width:
- 1.96 in
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Height:
- 5.66 in
- [Ue] Rated Operational Voltage:
- 600Y/347 V AC
- Mounting Mode:
- bolt-on
- Holding Current:
- 630 A
- Breaking Capacity:
- 18 kA 600Y/347 V AC
- Protection Type:
- overload || short-circuit
- Tightening Torque:
- 3.9-3.9 N.m 2.5-6 mm² (AWG 14...AWG 10) || 5.6-5.6 N.m 10-70 mm² (AWG 8...AWG 2/0)
- Number Of Poles:
- 2
- Ambient Air Temperature For Operation:
- 40 °C
- Line Rated Current:
- 70 A
- Product Destination:
- NF panelboard
- Breaking Capacity Code:
- G
- Module Type:
- E-Frame
- Product Certifications:
- cULus
- Device Short Name:
- EGB
- Mercury Free:
- Yes
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- China Rohs Regulation:
- Product out of China RoHS scope. Substance declaration for your information.
- Rohs Exemption Information:
- Yes
- Trip Unit Rating:
- 1800-1800 A
- Local Signalling:
- trip indicator
- Awg Gauge:
- AWG 12...AWG 2/0 aluminium || AWG 14...AWG 2/0 copper
