Schneider Electric EJB26015 Miniature Circuit Breaker 600V 15A

(No reviews yet) Write a Review

Write a Review

Schneider Electric EJB26015 Miniature Circuit Breaker 600V 15A

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

EJB26015

UPC:

785901405351

MPN:

Condition:

New

Number Of Poles:

2

Trip Unit Technology:

thermal-magnetic

Holding Current:

270 A

Ambient Air Temperature For Operation:

40 °C

Module Type:

E-Frame

Product Certifications:

cULus

Number Of Spaces Required:

2

China Rohs Regulation:

Product out of China RoHS scope. Substance declaration for your information.

Width:

1.96 in

Warranty:

18 months

Range Of Product:

125 A Frame EDB-EGB-EJB

Product Destination:

NF panelboard

Device Short Name:

EJB

Awg Gauge:

AWG 12...AWG 6 aluminium || AWG 14...AWG 6 copper

Depth:

4.05 in

Rohs Exemption Information:

Yes

Reach Regulation:

Reference contains Substances of Very High Concern above the threshold

[Ue] Rated Operational Voltage:

600Y/347 V AC

Number Of Spaces:

2

Line Rated Current:

15 A

Height:

5.66 in

Circuit Breaker Application:

HACR rated

Local Signalling:

trip indicator

Trip Unit Rating:

875-875 A

Breaking Capacity:

25 kA 600Y/347 V AC

Mounting Mode:

bolt-on

Breaking Capacity Code:

J

Product Or Component Type:

circuit-breaker

Net Weight:

3 lb(US)

Electrical Connection:

lugs aluminium

Protection Type:

short-circuit || overload

Eu Rohs Directive:

Pro-active compliance (Product out of EU RoHS legal scope)

Mercury Free:

Yes

Tightening Torque:

3.4-3.4 N.m 2.5-16 mm² (AWG 14...AWG 6)

Brochure:

View

Datasheet:

View
