Schneider Electric EJB34040CA Miniature Circuit Breaker 480Y/277V 40A

(No reviews yet) Write a Review
SKU:
EJB34040CA
UPC:
3.60649E+12
Condition:
New
Number Of Poles:
3
Depth:
4.05 in
Electrical Connection:
lugs aluminium
Mounting Mode:
bolt-on
Holding Current:
630 A
Awg Gauge:
AWG 12...AWG 2/0 aluminium || AWG 14...AWG 2/0 copper
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Breaking Capacity Code:
J
Ambient Air Temperature For Operation:
50 °C
Mercury Free:
Yes
Circuit Breaker Application:
HACR rated || HID rated
Number Of Spaces Required:
3
Module Type:
E-Frame
Range Of Product:
125 A Frame EDB-EGB-EJB
Height:
5.66 in
Product Destination:
NF panelboard
Eu Rohs Directive:
Pro-active compliance (Product out of EU RoHS legal scope)
Net Weight:
4 lb(US)
Rohs Exemption Information:
Yes
Line Rated Current:
40 A
Tightening Torque:
3.9-3.9 N.m 2.5-6 mm² (AWG 14...AWG 10) || 5.6-5.6 N.m 10-70 mm² (AWG 8...AWG 2/0)
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Breaking Capacity:
65 kA 277 V AC || 100 kA 240 V AC || 65 kA 480Y/277 V AC || 100 kA 120 V AC || 100 kA 120/240 V AC
Trip Unit Rating:
1800-1800 A
Local Signalling:
trip indicator
Protection Type:
short-circuit || overload
Device Short Name:
EJB
Trip Unit Technology:
thermal-magnetic
Number Of Spaces:
3
Product Certifications:
cULus
[Ue] Rated Operational Voltage:
480Y/277 V AC
Product Or Component Type:
miniature circuit-breaker
Width:
2.94 in
Catalog:
View
Datasheet:
View
  • Schneider Electric EJB34040CA Miniature Circuit Breaker 480Y/277V 40A
  • Schneider Electric EJB34040CA Miniature Circuit Breaker 480Y/277V 40A
$1,630.00

Description

E-Frame Breaker are Lighting Panelboard Circuit breakers that are proven effective and reliable which provide a wide variety or robust features that are use specifically in Square D NF Panelboards. This range of breaker is ideally designed to offer superior overload and short circuit protection. All E-Frame breakers have a thermal-magnetic trip unit as well as signal indicator that will indicate when a trip has occur. Mounting bolts are used to hold these breakers in place. This E-Frame breaker is 40A, 3 pole, and has an operating voltage of 480Y/277 VAC. It also provides a 100 kA max interrupt rating at 120 VAC. This device has a hold current of 630A which is the maximum current the breaker can be held to ensure it will trip and a trip current of 1800A which is the current value when the breaker is guaranteed to trip. Many accessories are available for this breaker. This breaker was calibrated for 50 degrees C. This product is UL Listed as High Intensity Discharge. HACR rated.
