Schneider Electric GBX120010K Planetary Gear Box 120Mm, Ratio 10

Schneider Electric GBX120010K Planetary Gear Box 120Mm, Ratio 10

Schneider Electric
SKU:
GBX120010K
|
UPC:
3606485317502
$1,048.15
(No reviews yet) Write a Review
Condition:
New
Current Stock:
Description
gearbox straight teeth GBX, Lexium, 120mm, reduction 10:1 , 7arc.min, 95N.m
Additional Information
Maximum Axial Force Fa:
2100 N 100 rpm, during 30000 hour at 30°C
Shaft Material:
C 45
Additional Information:
lubricated for life
Eu Rohs Directive:
Pro-active compliance (Product out of EU RoHS legal scope)
Pvc Free:
Yes
Product Or Component Type:
planetary gearbox
Efficiency:
0.96
Housing Colour:
black
Device Short Name:
GBX
Reduction Ratio:
0.417361111111111
Service Life In Hours:
30000 h 100 rpm 30 °C
Shaft Moment Of Inertia:
1.3 kg.cm²
Gear Box Type:
straight teeth
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
California Proposition 65:
WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Housing Material:
black anodized aluminium
Rohs Exemption Information:
Yes
Continuous Output Torque:
95 N.m 100 rpm 30 °C
Ambient Air Temperature For Operation:
-25-90 °C
Gearbox External Diameter:
120 mm
Noise Level:
65 dB 1 m, no-load
Net Weight:
6 kg
Torsional Rigidity:
12 N.m/arcmin
Maximum Radial Force Fr:
1500 N 100 rpm, force applied at mid-distance from output shaft during 30000 hour at 30 °C
Mercury Free:
Yes
Maximum Output Torque:
152 N.m 100 rpm 30 °C
Reach Regulation:
Free of Substances of Very High Concern above the threshold
Maximum Torsional Backlash:
7 arc.min
Mounting Position:
any position
Internal Diameter:
24.0 mm
Reach Free Of Svhc:
Yes
Range Compatibility:
Lexium 32 || Lexium 62 || Lexium 28 || Lexium 62 ILM || Lexium 52
Product Compatibility:
BMH 100 mm, 3 || BSH 100 mm, 1 || BSH 100 mm, 3 || BCH2 100 mm, 1 || BCH2 130 mm, 1 || SH3 || MH3 || ILM
Ip Degree Of Protection:
shaft output IP54
