Schneider Electric GS1AP43 Terminal Cover 3X250A
Schneider Electric
$132.00
(No reviews yet)
Write a Review
Write a Review
Schneider Electric
Schneider Electric GS1AP43 Terminal Cover 3X250A
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
TeSys GS accessory, protection terminal shroud for 3-pole 200-400A IEC fuse switch-disconnectors GS1M, GS1N, GS1P, GS1Q, GS2M, GS2N, GS2P, GS2Q and 200A UL GS2MU. Made with a semi-transparent isolating material, the shroud protects against direct contact on terminals by providing a front face IP20 protection level. It can be used for upstream or downstream protection (2 pieces are necessary for full protection). Green Premium compliant (RoHS/REACh).
- Line Rated Current:
- 160 A || 200 A || 250 A || 315 A || 400 A
- Device Short Name:
- GS1AP
- Toxic Heavy Metal Free:
- Yes
- Mercury Free:
- Yes
- China Rohs Regulation:
- X
- Standards:
- IEC
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Styrene, which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov
- Reach Regulation:
- Free of Substances of Very High Concern above the threshold
- Accessory / Separate Part Category:
- protection accessory
- Rohs Exemption Information:
- Yes
- Net Weight:
- 0.25 kg
- Eu Rohs Directive:
- Compliant
- Warranty:
- 18 months
- Circularity Profile:
- ENVEOLI2003007EN
- Product Or Component Type:
- terminal shroud
- Sustainable Offer Status:
- Green Premium product
- Reach Free Of Svhc:
- Yes
- Environmental Disclosure:
- ENVPEP2003007EN
- Poles Description:
- 3P
- Range:
- TeSys
- Range Compatibility:
- TeSys TeSys GS GS2M || TeSys TeSys GS GS2N || TeSys TeSys GS GS2P || TeSys TeSys GS GS2Q || FuPact FuPacT GS GSB200 || FuPact FuPacT GS GSB250 || FuPact FuPacT GS GSD250 || FuPact FuPacT GS GSB400 || FuPact FuPacT GS GSD400
- Catalog:
- View
- Datasheet:
- View
