Schneider Electric GV4AS287 Coil St Mx 208-277V 50/60Hz For Gv4 Bv4

Schneider Electric GV4AS287 Coil St Mx 208-277V 50/60Hz For Gv4 Bv4

Schneider Electric
SKU:
GV4AS287
|
UPC:
3606485444918
$185.00
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
TeSys GV electrical trip unit, MX shunt trip, 208-240V AC 50Hz/60Hz, for motor circuit breakers GV4. It trips the circuit breaker when the control voltage is applied in limits 0.7-1.1 Uc with an impulse duration greater than 20ms or a maintained signal. To be plugged inside the circuit breaker, connection by spring terminals. Multi standards certified (IEC, UL, CSA, CCC, EAC), Green Premium compliant (RoHS/REACh).
Additional Information
Device Short Name:
MX
Mounting Mode:
internal mounting
Rohs Exemption Information:
Yes
Mechanical Durability:
20000 cycles
Weee:
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Impulse Duration:
>= 20 ms
Wire Stripping Length:
8 mm
Product Or Component Type:
voltage release
Eu Rohs Directive:
Compliant with Exemptions
Operating Time:
< 50 ms
Threshold Tripping Voltage:
0.7...1.1 Un failsafe opening || < 0.7 Un possible opening
Environmental Disclosure:
ENVPEP2311043EN
Mercury Free:
Yes
Quantity Per Set:
set of 1
California Proposition 65:
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
Circularity Profile:
ENVEOLI2311043EN
Connections - Terminals:
spring terminals 1 0.5-1.5 mm² - cable stiffness: flexible without cable end
[Ui] Rated Insulation Voltage:
277 V IEC 60947-1
Voltage Release Type:
shunt trip release
Range Compatibility:
TeSys TeSys GV4 || TeSys TeSys BV4
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
[Uc] Control Circuit Voltage:
277 V AC 60 Hz || 220...240 V AC 50 Hz || 208...240 V AC 60 Hz
Maximum Inrush Power In Va:
6 VA
Maximum Hold-In Power Consumption In Va:
10 VA
Range:
TeSys
Device Application:
control
