Schneider Electric HDA260604 Molded Case Circuit Breaker 600V 60A

Schneider Electric HDA260604 Molded Case Circuit Breaker 600V 60A

Schneider Electric
SKU:
HDA260604
|
UPC:
7.85902E+11
Availability:
Contact us to confirm availability and lead times.
$899.00
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
PowerPacT H-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT H-Frame circuit breakers are available with either thermal magnetic or Micrologic electronic trip protection units. This PowerPacT H-Frame circuit breaker provides thermal magnetic circuit protection with a breaking capacity of 14kA at 600VAC. All PowerPacT H-Frame circuit breakers are equipped with dual-break rotating contacts that reduce the amount of peak current during a short circuit fault. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT H circuit breakers are available in 2 and 3-pole unit mount and I-Line constructions. PowerPacT H I-Line circuit breakers are available in I-Line construction for easy installation and removal in I-Line applications. This breaker has I-Line terminations on the line side and mechanical lugs on the load side. This PowerPacT H, 60A, 2 pole, circuit breaker has a breaking capacity of 14kA at 600VAC. This circuit breaker has a continuous current rating of 80% with a BC phase connection. PowerPacT H circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
Additional Information
Phase Connection:
BC
Mercury Free:
Yes
Terminal Identifier:
AL150HD
Magnetic Hold Current:
800 A
Ambient Air Temperature For Storage:
-50-85 °C
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Product Or Component Type:
circuit breaker
California Proposition 65:
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
Pollution Degree:
3 IEC 60947-1
Device Application:
distribution
Net Weight:
2.2 kg
Height:
163 mm
Mounting Mode:
I-Line bracket)
Warranty:
18 months
Depth:
86 mm
Mounting Height:
3 in
[Ue] Rated Operational Voltage:
690 V AC 50/60 Hz IEC 60947-3
Protected Poles Description:
2t
Eu Rohs Directive:
Compliant with Exemptions
Trip Unit Technology:
thermal-magnetic
Magnetic Tripping Current:
1450-1450 A
Number Of Slots:
2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
Breaking Capacity Code:
D
Circuit Breaker Application:
HACR rated
Product Name:
PowerPact H
Breaking Capacity:
25 kA 240 V AC 50/60 Hz UL 489 || 18 kA 480 V AC 50/60 Hz || 14 kA 600 V AC 50/60 Hz || 20 kA 250 V DC
Environmental Disclosure:
ENVPEP2206027EN
Utilisation Category:
category A
Width:
104 mm
Wire Stripping Length:
16 mm
Tightening Torque:
5-5 N.m 2.5-6 mm² (AWG 14...AWG 10) || 14-14 N.m 10-95 mm² (AWG 8...AWG 3/0)
Communication Interface:
Modbus || Ethernet
Continuous Current Rating:
0.8
Suitability For Isolation:
yes IEC 60947-2
Color:
Black
Network Frequency:
50/60 Hz
Circularity Profile:
ENVEOLI2206027EN
[Ui] Rated Insulation Voltage:
750 V IEC 60947-2
Poles Description:
2P
Rohs Exemption Information:
Yes
Operating Altitude:
< 6561.68 ft (2000 m) without derating || 5000 m with derating
Control Type:
toggle
Ambient Air Temperature For Operation:
-2-70 °C
Range:
PowerPact
Mounting Support:
bracket
Quality Labels:
CE
Awg Gauge:
AWG 14...AWG 3/0 aluminium/copper terminal
Product Certifications:
UL || CSA || NOM
Local Signalling:
switched off (OFF) 1 trip indicator green)
Line Rated Current:
60-60 A
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Sustainable Offer Status:
Green Premium product
[Ics] Rated Service Breaking Capacity:
25 kA 220/240 V AC 50/60 Hz IEC 60947-2 || 18 kA 380/440/415 V AC 50/60 Hz IEC 60947-2 || 14 kA 500/525 V AC 50/60 Hz IEC 60947-2 || 20 kA 250 V DC IEC 60947-2 || 20 kA 500 V DC IEC 60947-2
Electrical Connection:
I-Line connection, line || lugs, load
Standards:
UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
Ip Degree Of Protection:
front cover IP40 IEC 60529
[Uimp] Rated Impulse Withstand Voltage:
8 kV IEC 60947-2
Pvc Free:
Yes
Quantity Per Set:
1
