Schneider Electric HDA261102 Molded Case Circuit Breaker 600V 110A
Schneider Electric
$3,292.50
(No reviews yet)
Write a Review
Write a Review
Schneider Electric
Schneider Electric HDA261102 Molded Case Circuit Breaker 600V 110A
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
PowerPacT H-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT H-Frame circuit breakers are available with either thermal magnetic or Micrologic electronic trip protection units. This PowerPacT H-Frame circuit breaker provides thermal magnetic circuit protection with a breaking capacity of 14kA at 600VAC. All PowerPacT H-Frame circuit breakers are equipped with dual-break rotating contacts that reduce the amount of peak current during a short circuit fault. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT H circuit breakers are available in 2 and 3-pole unit mount and I-Line constructions. PowerPacT H I-Line circuit breakers are available in I-Line construction for easy installation and removal in I-Line applications. This breaker has I-Line terminations on the line side and mechanical lugs on the load side. This PowerPacT H, 110A, 2 pole, circuit breaker has a breaking capacity of 14kA at 600VAC. This circuit breaker has a continuous current rating of 80% with an AC phase connection. PowerPacT H circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
- Circuit Breaker Application:
- HACR rated
- [Uimp] Rated Impulse Withstand Voltage:
- 8 kV IEC 60947-2
- Magnetic Tripping Current:
- 1700-1700 A
- Color:
- Black
- Control Type:
- toggle
- Ambient Air Temperature For Operation:
- -2-70 °C
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
- Pvc Free:
- Yes
- Trip Unit Technology:
- thermal-magnetic
- Electrical Connection:
- I-Line connection, line || lugs, load
- Network Frequency:
- 50/60 Hz
- Ambient Air Temperature For Storage:
- -50-85 °C
- Breaking Capacity Code:
- D
- Awg Gauge:
- AWG 14...AWG 3/0 aluminium/copper terminal
- Net Weight:
- 2.2 kg
- Product Or Component Type:
- circuit breaker
- [Ue] Rated Operational Voltage:
- 690 V AC 50/60 Hz IEC 60947-3
- Standards:
- UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
- Number Of Slots:
- 2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
- Range:
- PowerPact
- Terminal Identifier:
- AL150HD
- [Ics] Rated Service Breaking Capacity:
- 25 kA 220/240 V AC 50/60 Hz IEC 60947-2 || 18 kA 380/440/415 V AC 50/60 Hz IEC 60947-2 || 14 kA 500/525 V AC 50/60 Hz IEC 60947-2 || 20 kA 250 V DC IEC 60947-2 || 20 kA 500 V DC IEC 60947-2
- Pollution Degree:
- 3 IEC 60947-1
- Width:
- 104 mm
- [Ui] Rated Insulation Voltage:
- 750 V IEC 60947-2
- Mounting Support:
- bracket
- Mounting Mode:
- I-Line bracket)
- Operating Altitude:
- < 6561.68 ft (2000 m) without derating || 5000 m with derating
- Breaking Capacity:
- 25 kA 240 V AC 50/60 Hz UL 489 || 18 kA 480 V AC 50/60 Hz || 14 kA 600 V AC 50/60 Hz || 20 kA 250 V DC
- Height:
- 163 mm
- Phase Connection:
- AC
- Continuous Current Rating:
- 0.8
- Rohs Exemption Information:
- Yes
- Quantity Per Set:
- 1
- Circularity Profile:
- ENVEOLI1311006EN
- Device Application:
- distribution
- Protected Poles Description:
- 2t
- Depth:
- 86 mm
- Suitability For Isolation:
- yes IEC 60947-2
- Tightening Torque:
- 5-5 N.m 2.5-6 mm² (AWG 14...AWG 10) || 14-14 N.m 10-95 mm² (AWG 8...AWG 3/0)
- Ip Degree Of Protection:
- front cover IP40 IEC 60529
- Mercury Free:
- Yes
- Line Rated Current:
- 110-110 A
- China Rohs Regulation:
- Product out of China RoHS scope. Substance declaration for your information.
- Mounting Height:
- 3 in
- Quality Labels:
- CE
- Poles Description:
- 2P
- Local Signalling:
- switched off (OFF) 1 trip indicator green)
- Sustainable Offer Status:
- Green Premium product
- Communication Interface:
- Modbus || Ethernet
- Product Certifications:
- UL || CSA || NOM
- Wire Stripping Length:
- 16 mm
- Product Name:
- PowerPact H
- Utilisation Category:
- category A
- Magnetic Hold Current:
- 900 A
- Warranty:
- 18 months
- Environmental Disclosure:
- ENVPEP1311006EN
- Eu Rohs Directive:
- Compliant
