Schneider Electric HDF36070 Molded Case Circuit Breaker 600V 70A
Schneider Electric
$1,328.00
(No reviews yet)
Write a Review
Write a Review
Schneider Electric
Schneider Electric HDF36070 Molded Case Circuit Breaker 600V 70A
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
PowerPacT H-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT H-Frame circuit breakers are available with either thermal magnetic or Micrologic electronic trip protection units. This PowerPacT H-Frame circuit breaker provides thermal magnetic circuit protection with a breaking capacity of 14kA at 600VAC. All PowerPacT H-Frame circuit breakers are equipped with dual-break rotating contacts that reduce the amount of peak current during a short circuit fault. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT H circuit breakers are available in 2 and 3-pole unit mount and I-Line constructions. This breaker has a busbar connection. This PowerPacT H, 70A, 3 pole, circuit breaker has a breaking capacity of 14kA at 600VAC. This circuit breaker has a continuous current rating of 80%. PowerPacT H circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
- Rohs Exemption Information:
- Yes
- Color:
- Black
- Circuit Breaker Application:
- HACR rated
- Width:
- 104 mm
- [Ui] Rated Insulation Voltage:
- 750 V IEC 60947-2
- Tightening Torque:
- 5-5 N.m 2.5-6 mm² (AWG 14...AWG 10) || 14-14 N.m 10-95 mm² (AWG 8...AWG 3/0)
- Pvc Free:
- Yes
- [Ue] Rated Operational Voltage:
- 690 V AC 50/60 Hz IEC 60947-3
- China Rohs Regulation:
- Product out of China RoHS scope. Substance declaration for your information.
- Awg Gauge:
- AWG 14...AWG 3/0 aluminium/copper terminal
- Environmental Disclosure:
- ENVPEP2206027EN
- Suitability For Isolation:
- yes IEC 60947-2
- Protected Poles Description:
- 3t
- Local Signalling:
- switched off (OFF) 1 trip indicator green)
- Product Certifications:
- UL || CSA || NOM
- [Ics] Rated Service Breaking Capacity:
- 25 kA 220/240 V AC 50/60 Hz IEC 60947-2 || 18 kA 380/440/415 V AC 50/60 Hz IEC 60947-2 || 14 kA 500/525 V AC 50/60 Hz IEC 60947-2 || 20 kA 250 V DC IEC 60947-2 || 20 kA 500 V DC IEC 60947-2
- Magnetic Hold Current:
- 800 A
- Circularity Profile:
- ENVEOLI2206027EN
- Ambient Air Temperature For Storage:
- -50-85 °C
- Operating Altitude:
- < 6561.68 ft (2000 m) without derating || 5000 m with derating
- Breaking Capacity Code:
- D
- Depth:
- 86 mm
- Electrical Connection:
- busbar connection, line || busbar connection, load
- Trip Unit Technology:
- thermal-magnetic
- Mercury Free:
- Yes
- Net Weight:
- 2.2 kg
- Height:
- 163 mm
- Continuous Current Rating:
- 0.8
- Quantity Per Set:
- 1
- Mounting Mode:
- unit mount busbar)
- Network Frequency:
- 50/60 Hz
- Eu Rohs Directive:
- Compliant with Exemptions
- Product Or Component Type:
- circuit breaker
- Range:
- PowerPact
- Utilisation Category:
- category A
- Standards:
- UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
- Quality Labels:
- CE
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
- Communication Interface:
- Modbus || Ethernet
- Ambient Air Temperature For Operation:
- -2-70 °C
- Number Of Slots:
- 2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
- Warranty:
- 18 months
- Wire Stripping Length:
- 16 mm
- Terminal Identifier:
- AL150HD
- [Uimp] Rated Impulse Withstand Voltage:
- 8 kV IEC 60947-2
- Pollution Degree:
- 3 IEC 60947-1
- Line Rated Current:
- 70-70 A
- Mounting Support:
- busbar
- Device Application:
- distribution
- Breaking Capacity:
- 25 kA 240 V AC 50/60 Hz UL 489 || 18 kA 480 V AC 50/60 Hz || 14 kA 600 V AC 50/60 Hz || 20 kA 250 V DC
- Magnetic Tripping Current:
- 1450-1450 A
- Poles Description:
- 3P
- Ip Degree Of Protection:
- front cover IP40 IEC 60529
- Product Name:
- PowerPact H
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Sustainable Offer Status:
- Green Premium product
- Control Type:
- toggle
- Brochure:
- View
- Catalog:
- View
- Datasheet:
- View
