Schneider Electric HDL36040C Molded Case Circuit Breaker 600V 40A
Schneider Electric
$1,305.00
(No reviews yet)
Write a Review
Write a Review
Schneider Electric
Schneider Electric HDL36040C Molded Case Circuit Breaker 600V 40A
PowerPacT H-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT H-Frame circuit breakers are available with either thermal magnetic or Micrologic electronic trip protection units. This PowerPacT H-Frame circuit breaker provides thermal magnetic circuit protection with a breaking capacity of 14kA at 600VAC. All PowerPacT H-Frame circuit breakers are equipped with dual-break rotating contacts that reduce the amount of peak current during a short circuit fault. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT H circuit breakers are available in 2 and 3-pole unit mount and I-Line constructions. This breaker has lugs on both the line and load sides. This PowerPacT H, 40A, 3 pole, circuit breaker has a breaking capacity of 14kA at 600VAC. This circuit breaker has a continuous current rating of 100%. PowerPacT H circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
- [Ue] Rated Operational Voltage:
- 690 V AC 50/60 Hz IEC 60947-3
- Breaking Capacity:
- 25 kA 240 V AC 50/60 Hz UL 489 || 18 kA 480 V AC 50/60 Hz || 14 kA 600 V AC 50/60 Hz || 20 kA 250 V DC
- [Uimp] Rated Impulse Withstand Voltage:
- 8 kV IEC 60947-2
- Device Application:
- distribution
- Depth:
- 86 mm
- Magnetic Tripping Current:
- 850-850 A
- Range:
- PowerPact
- Standards:
- UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
- Sustainable Offer Status:
- Green Premium product
- Net Weight:
- 2.2 kg
- [Ui] Rated Insulation Voltage:
- 750 V IEC 60947-2
- Local Signalling:
- switched off (OFF) 1 trip indicator green)
- Environmental Disclosure:
- ENVPEP2206027EN
- Wire Stripping Length:
- 16 mm
- Ambient Air Temperature For Storage:
- -50-85 °C
- Mounting Mode:
- unit mount lug)
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Network Frequency:
- 50/60 Hz
- Suitability For Isolation:
- yes IEC 60947-2
- [Ics] Rated Service Breaking Capacity:
- 25 kA 220/240 V AC 50/60 Hz IEC 60947-2 || 18 kA 380/440/415 V AC 50/60 Hz IEC 60947-2 || 14 kA 500/525 V AC 50/60 Hz IEC 60947-2 || 20 kA 250 V DC IEC 60947-2 || 20 kA 500 V DC IEC 60947-2
- Operating Altitude:
- < 6561.68 ft (2000 m) without derating || 5000 m with derating
- Product Name:
- PowerPact H
- Eu Rohs Directive:
- Compliant with Exemptions
- China Rohs Regulation:
- Product out of China RoHS scope. Substance declaration for your information.
- Product Certifications:
- UL || CSA || NOM
- Width:
- 104 mm
- Mercury Free:
- Yes
- Rohs Exemption Information:
- Yes
- Quantity Per Set:
- 1
- Line Rated Current:
- 40-40 A
- Product Or Component Type:
- circuit breaker
- Ambient Air Temperature For Operation:
- -2-70 °C
- Electrical Connection:
- lugs, line || lugs, load
- Circuit Breaker Application:
- HACR rated
- Terminal Identifier:
- AL150HD
- Trip Unit Technology:
- thermal-magnetic
- Tightening Torque:
- 5-5 N.m 2.5-6 mm² (AWG 14...AWG 10) || 14-14 N.m 10-95 mm² (AWG 8...AWG 3/0)
- Warranty:
- 18 months
- Continuous Current Rating:
- 1
- Awg Gauge:
- AWG 14...AWG 3/0 aluminium/copper terminal
- Pvc Free:
- Yes
- Quality Labels:
- CE
- Circularity Profile:
- ENVEOLI2206027EN
- Communication Interface:
- Modbus || Ethernet
- Protected Poles Description:
- 3t
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
- Breaking Capacity Code:
- D
- Height:
- 163 mm
- Number Of Slots:
- 2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
- Color:
- Black
- Magnetic Hold Current:
- 400 A
- Poles Description:
- 3P
- Ip Degree Of Protection:
- front cover IP40 IEC 60529
- Mounting Support:
- lug
- Utilisation Category:
- category A
- Control Type:
- toggle
- Pollution Degree:
- 3 IEC 60947-1
