Schneider Electric HDL36040SA Molded Case Circuit Breaker 600V 40A
Schneider Electric
$2,707.50
(No reviews yet)
Write a Review
Write a Review
Schneider Electric
Schneider Electric HDL36040SA Molded Case Circuit Breaker 600V 40A
PowerPacT H-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT H-Frame circuit breakers are available with either thermal magnetic or Micrologic electronic trip protection units. This PowerPacT H-Frame circuit breaker provides thermal magnetic circuit protection with a breaking capacity of 14kA at 600VAC. All PowerPacT H-Frame circuit breakers are equipped with dual-break rotating contacts that reduce the amount of peak current during a short circuit fault. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT H circuit breakers are available in 2 and 3-pole unit mount and I-Line constructions. This breaker has lugs on both the line and load sides. This PowerPacT H, 40A, 3 pole, circuit breaker has a breaking capacity of 14kA at 600VAC. This circuit breaker has a continuous current rating of 80%. This unit includes a factory installed 120VAC shunt trip. PowerPacT H circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
- Magnetic Hold Current:
- 400 A
- Ambient Air Temperature For Operation:
- -2-70 °C
- Breaking Capacity Code:
- D
- [Ui] Rated Insulation Voltage:
- 750 V IEC 60947-2
- Tightening Torque:
- 5-5 N.m 2.5-6 mm² (AWG 14...AWG 10) || 14-14 N.m 10-95 mm² (AWG 8...AWG 3/0)
- [Ics] Rated Service Breaking Capacity:
- 25 kA 220/240 V AC 50/60 Hz IEC 60947-2 || 18 kA 380/440/415 V AC 50/60 Hz IEC 60947-2 || 14 kA 500/525 V AC 50/60 Hz IEC 60947-2 || 20 kA 250 V DC IEC 60947-2 || 20 kA 500 V DC IEC 60947-2
- Width:
- 104 mm
- Device Application:
- distribution
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Accessory / Separate Part Type:
- shunt trip 110...130 V AC compartment
- [Uimp] Rated Impulse Withstand Voltage:
- 8 kV IEC 60947-2
- Utilisation Category:
- category A
- Protected Poles Description:
- 3t
- Quality Labels:
- CE
- Product Or Component Type:
- circuit breaker
- Height:
- 163 mm
- Network Frequency:
- 50/60 Hz
- Depth:
- 86 mm
- Product Name:
- PowerPact H
- Pollution Degree:
- 3 IEC 60947-1
- Environmental Disclosure:
- ENVPEP2206027EN
- Rohs Exemption Information:
- Yes
- Product Certifications:
- UL || CSA || NOM
- Quantity Per Set:
- 1
- Local Signalling:
- switched off (OFF) 1 trip indicator green)
- Suitability For Isolation:
- yes IEC 60947-2
- Continuous Current Rating:
- 0.8
- Operating Altitude:
- < 6561.68 ft (2000 m) without derating || 5000 m with derating
- Range:
- PowerPact
- Trip Unit Technology:
- thermal-magnetic
- Ip Degree Of Protection:
- front cover IP40 IEC 60529
- Eu Rohs Directive:
- Compliant with Exemptions
- Wire Stripping Length:
- 16 mm
- Electrical Connection:
- lugs, line || lugs, load
- Awg Gauge:
- AWG 14...AWG 3/0 aluminium/copper terminal
- Poles Description:
- 3P
- Mounting Mode:
- unit mount lug)
- Circularity Profile:
- ENVEOLI2206027EN
- Breaking Capacity:
- 25 kA 240 V AC 50/60 Hz UL 489 || 18 kA 480 V AC 50/60 Hz || 14 kA 600 V AC 50/60 Hz || 20 kA 250 V DC
- Magnetic Tripping Current:
- 850-850 A
- Number Of Slots:
- 2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
- Line Rated Current:
- 40-40 A
- Control Type:
- toggle
- Communication Interface:
- Modbus || Ethernet
- Net Weight:
- 2.2 kg
- Warranty:
- 18 months
- Mounting Support:
- lug
- Circuit Breaker Application:
- HACR rated
- Ambient Air Temperature For Storage:
- -50-85 °C
- [Ue] Rated Operational Voltage:
- 690 V AC 50/60 Hz IEC 60947-3
- Mercury Free:
- Yes
- Terminal Identifier:
- AL150HD
- Standards:
- UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
- China Rohs Regulation:
- Product out of China RoHS scope. Substance declaration for your information.
- Sustainable Offer Status:
- Green Premium product
- Pvc Free:
- Yes
- Color:
- Black
