Schneider Electric HDL36110C Molded Case Circuit Breaker 600V 110A

(No reviews yet) Write a Review

Write a Review

Schneider Electric HDL36110C Molded Case Circuit Breaker 600V 110A

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

HDL36110C

UPC:

785901921868

MPN:

Condition:

New

Network Frequency:

50/60 Hz

Warranty:

18 months

Magnetic Tripping Current:

1700-1700 A

Product Name:

PowerPact H

Pvc Free:

Yes

Product Certifications:

UL || CSA || NOM

Range:

PowerPact

Control Type:

toggle

Breaking Capacity Code:

D

Quantity Per Set:

1

Color:

Black

[Uimp] Rated Impulse Withstand Voltage:

8 kV IEC 60947-2

Poles Description:

3P

[Ue] Rated Operational Voltage:

690 V AC 50/60 Hz IEC 60947-3

[Ui] Rated Insulation Voltage:

750 V IEC 60947-2

Mounting Mode:

unit mount lug)

Operating Altitude:

< 6561.68 ft (2000 m) without derating || 5000 m with derating

Product Or Component Type:

circuit breaker

Depth:

86 mm

Quality Labels:

CE

Breaking Capacity:

25 kA 240 V AC 50/60 Hz UL 489 || 18 kA 480 V AC 50/60 Hz || 14 kA 600 V AC 50/60 Hz || 20 kA 250 V DC

Communication Interface:

Modbus || Ethernet

Ambient Air Temperature For Operation:

-2-70 °C

Trip Unit Technology:

thermal-magnetic

Wire Stripping Length:

16 mm

Ip Degree Of Protection:

front cover IP40 IEC 60529

Continuous Current Rating:

1

Ambient Air Temperature For Storage:

-50-85 °C

Mercury Free:

Yes

Line Rated Current:

110-110 A

California Proposition 65:

WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information

Reach Regulation:

Reference contains Substances of Very High Concern above the threshold

Protected Poles Description:

3t

Device Application:

distribution

Magnetic Hold Current:

900 A

Suitability For Isolation:

yes IEC 60947-2

Number Of Slots:

2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)

Circularity Profile:

ENVEOLI2206027EN

Awg Gauge:

AWG 14...AWG 3/0 aluminium/copper terminal

Standards:

UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2

Terminal Identifier:

AL150HD

Net Weight:

2.2 kg

Sustainable Offer Status:

Green Premium product

Eu Rohs Directive:

Compliant with Exemptions

Rohs Exemption Information:

Yes

Electrical Connection:

lugs, line || lugs, load

Mounting Support:

lug

[Ics] Rated Service Breaking Capacity:

25 kA 220/240 V AC 50/60 Hz IEC 60947-2 || 18 kA 380/440/415 V AC 50/60 Hz IEC 60947-2 || 14 kA 500/525 V AC 50/60 Hz IEC 60947-2 || 20 kA 250 V DC IEC 60947-2 || 20 kA 500 V DC IEC 60947-2

Height:

163 mm

Width:

104 mm

Circuit Breaker Application:

HACR rated

Environmental Disclosure:

ENVPEP2206027EN

Utilisation Category:

category A

Tightening Torque:

5-5 N.m 2.5-6 mm² (AWG 14...AWG 10) || 14-14 N.m 10-95 mm² (AWG 8...AWG 3/0)

Pollution Degree:

3 IEC 60947-1

China Rohs Regulation:

Product out of China RoHS scope. Substance declaration for your information.

Local Signalling:

switched off (OFF) 1 trip indicator green)
