Schneider Electric HDM36100 Molded Case Circuit Breaker 600V 100A

Schneider Electric HDM36100 Molded Case Circuit Breaker 600V 100A

Schneider Electric
SKU:
HDM36100
|
UPC:
3606486282199
Availability:
Contact us to confirm availability and lead times.
$1,328.00
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
PowerPacT H-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT H-Frame circuit breakers are available with either thermal magnetic or Micrologic electronic trip protection units. This PowerPacT H-Frame circuit breaker provides thermal magnetic circuit protection with a breaking capacity of 14kA at 600VAC. All PowerPacT H-Frame circuit breakers are equipped with dual-break rotating contacts that reduce the amount of peak current during a short circuit fault. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT H circuit breakers are available in 2 and 3-pole unit mount and I-Line constructions. This breaker has lugs on the line and terminal nuts on the load side. This PowerPacT H, 100A, 3 pole, circuit breaker has a breaking capacity of 14kA at 600VAC. This circuit breaker has a continuous current rating of 80%. PowerPacT H circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
Additional Information
Magnetic Tripping Current:
1700-1700 A
Quantity Per Set:
1
Operating Altitude:
< 6561.68 ft (2000 m) without derating || 5000 m with derating
Continuous Current Rating:
0.8
Network Frequency:
50/60 Hz
Circularity Profile:
ENVEOLI2206027EN
[Ics] Rated Service Breaking Capacity:
25 kA 220/240 V AC 50/60 Hz IEC 60947-2 || 18 kA 380/440/415 V AC 50/60 Hz IEC 60947-2 || 14 kA 500/525 V AC 50/60 Hz IEC 60947-2 || 20 kA 250 V DC IEC 60947-2 || 20 kA 500 V DC IEC 60947-2
Utilisation Category:
category A
Warranty:
18 months
Number Of Slots:
2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
Poles Description:
3P
Terminal Identifier:
AL150HD
Trip Unit Technology:
thermal-magnetic
Circuit Breaker Application:
HACR rated
Mounting Support:
lug
Quality Labels:
CE
Product Certifications:
UL || CSA || NOM
Electrical Connection:
lugs, line || terminal nut, load
Pollution Degree:
3 IEC 60947-1
Suitability For Isolation:
yes IEC 60947-2
Device Application:
distribution
Color:
Black
[Uimp] Rated Impulse Withstand Voltage:
8 kV IEC 60947-2
Sustainable Offer Status:
Green Premium product
Protected Poles Description:
3t
Breaking Capacity Code:
D
[Ue] Rated Operational Voltage:
690 V AC 50/60 Hz IEC 60947-3
Ambient Air Temperature For Operation:
-2-70 °C
California Proposition 65:
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
Standards:
UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
Local Signalling:
switched off (OFF) 1 trip indicator green)
Ambient Air Temperature For Storage:
-50-85 °C
[Ui] Rated Insulation Voltage:
750 V IEC 60947-2
Depth:
86 mm
Breaking Capacity:
25 kA 240 V AC 50/60 Hz UL 489 || 18 kA 480 V AC 50/60 Hz || 14 kA 600 V AC 50/60 Hz || 20 kA 250 V DC
Tightening Torque:
5-5 N.m 2.5-6 mm² (AWG 14...AWG 10) || 14-14 N.m 10-95 mm² (AWG 8...AWG 3/0)
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Height:
163 mm
Environmental Disclosure:
ENVPEP2206027EN
Eu Rohs Directive:
Compliant with Exemptions
Wire Stripping Length:
16 mm
Magnetic Hold Current:
900 A
Awg Gauge:
AWG 14...AWG 3/0 aluminium/copper terminal
Mounting Mode:
unit mount lug)
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Ip Degree Of Protection:
front cover IP40 IEC 60529
Width:
104 mm
Line Rated Current:
100-100 A
Rohs Exemption Information:
Yes
Range:
PowerPact
Mercury Free:
Yes
Net Weight:
2.2 kg
Product Or Component Type:
circuit breaker
Control Type:
toggle
Pvc Free:
Yes
Product Name:
PowerPact H
Communication Interface:
Modbus || Ethernet
