Schneider Electric HJA260302 Molded Case Circuit Breaker 600V 30A
Schneider Electric
$2,383.50
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
PowerPacT H-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT H-Frame circuit breakers are available with either thermal magnetic or Micrologic electronic trip protection units. This PowerPacT H-Frame circuit breaker provides thermal magnetic circuit protection with a breaking capacity of 25kA at 600VAC. All PowerPacT H-Frame circuit breakers are equipped with dual-break rotating contacts that reduce the amount of peak current during a short circuit fault. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT H circuit breakers are available in 2 and 3-pole unit mount and I-Line constructions. PowerPacT H I-Line circuit breakers are available in I-Line construction for easy installation and removal in I-Line applications. This breaker has I-Line terminations on the line side and mechanical lugs on the load side. This PowerPacT H, 30A, 2 pole, circuit breaker has a breaking capacity of 25kA at 600VAC. This circuit breaker has a continuous current rating of 80% with an AC phase connection. PowerPacT H circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
- Tightening Torque:
- 5-5 N.m 2.5-6 mm² (AWG 14...AWG 10) || 14-14 N.m 10-95 mm² (AWG 8...AWG 3/0)
- Depth:
- 86 mm
- Ambient Air Temperature For Operation:
- -2-70 °C
- [Ue] Rated Operational Voltage:
- 690 V AC 50/60 Hz IEC 60947-3
- Quantity Per Set:
- 1
- Continuous Current Rating:
- 0.8
- Phase Connection:
- AC
- Eu Rohs Directive:
- Compliant
- Poles Description:
- 2P
- Product Or Component Type:
- circuit breaker
- Quality Labels:
- CE
- Breaking Capacity Code:
- J
- Operating Altitude:
- < 6561.68 ft (2000 m) without derating || 5000 m with derating
- Magnetic Hold Current:
- 350 A
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
- Standards:
- UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
- Breaking Capacity:
- 100 kA 240 V AC 50/60 Hz UL 489 || 65 kA 480 V AC 50/60 Hz UL 489 || 25 kA 600 V AC 50/60 Hz UL 489 || 20 kA 250 V DC UL 489
- Sustainable Offer Status:
- Green Premium product
- Mounting Mode:
- I-Line bracket)
- Product Name:
- PowerPact H
- [Ui] Rated Insulation Voltage:
- 750 V IEC 60947-2
- Mercury Free:
- Yes
- Ambient Air Temperature For Storage:
- -50-85 °C
- Rohs Exemption Information:
- Yes
- Local Signalling:
- switched off (OFF) 1 trip indicator green)
- Width:
- 104 mm
- Control Type:
- toggle
- Utilisation Category:
- category A
- Protected Poles Description:
- 2t
- China Rohs Regulation:
- Product out of China RoHS scope. Substance declaration for your information.
- Range:
- PowerPact
- Product Certifications:
- UL || CSA || NOM
- Network Frequency:
- 50/60 Hz
- Electrical Connection:
- I-Line connection, line || lugs, load
- Circuit Breaker Application:
- HACR rated
- Line Rated Current:
- 30-30 A
- Circularity Profile:
- ENVEOLI1311006EN
- Trip Unit Technology:
- thermal-magnetic
- Wire Stripping Length:
- 16 mm
- Net Weight:
- 2.2 kg
- [Uimp] Rated Impulse Withstand Voltage:
- 8 kV IEC 60947-2
- Pvc Free:
- Yes
- Terminal Identifier:
- AL150HD
- Number Of Slots:
- 2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
- Magnetic Tripping Current:
- 750-750 A
- Mounting Support:
- bracket
- Height:
- 163 mm
- Mounting Height:
- 4.5 in
- Environmental Disclosure:
- ENVPEP1311006EN
- Ip Degree Of Protection:
- front cover IP40 IEC 60529
- Awg Gauge:
- AWG 14...AWG 3/0 aluminium/copper terminal
- Device Application:
- distribution
- Pollution Degree:
- 3 IEC 60947-1
- Warranty:
- 18 months
- Communication Interface:
- Modbus || Ethernet
- Color:
- Black
- Suitability For Isolation:
- yes IEC 60947-2
- [Ics] Rated Service Breaking Capacity:
- 100 kA 220/240 V AC 50/60 Hz IEC 60947-2 || 65 kA 380/440/415 V AC 50/60 Hz IEC 60947-2 || 25 kA 500/525 V AC 50/60 Hz IEC 60947-2 || 20 kA 250 V DC IEC 60947-2 || 20 kA 500 V DC IEC 60947-2
