Schneider Electric HJL36090SA Molded Case Circuit Breaker 600V 90A
Schneider Electric
$2,816.00
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
PowerPacT H-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT H-Frame circuit breakers are available with either thermal magnetic or Micrologic electronic trip protection units. This PowerPacT H-Frame circuit breaker provides thermal magnetic circuit protection with a breaking capacity of 25kA at 600VAC. All PowerPacT H-Frame circuit breakers are equipped with dual-break rotating contacts that reduce the amount of peak current during a short circuit fault. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT H circuit breakers are available in 2 and 3-pole unit mount and I-Line constructions. This breaker has lugs on both the line and load sides. This PowerPacT H, 90A, 3 pole, circuit breaker has a breaking capacity of 25kA at 600VAC. This circuit breaker has a continuous current rating of 80%. This unit includes a factory installed 120VAC shunt trip. PowerPacT H circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
- Circuit Breaker Application:
- HACR rated
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
- Pollution Degree:
- 3 IEC 60947-1
- Width:
- 104 mm
- Range:
- PowerPact
- Product Or Component Type:
- circuit breaker
- Communication Interface:
- Modbus || Ethernet
- Line Rated Current:
- 90-90 A
- Network Frequency:
- 50/60 Hz
- Sustainable Offer Status:
- Green Premium product
- Circularity Profile:
- ENVEOLI2206027EN
- Environmental Disclosure:
- ENVPEP2206027EN
- Local Signalling:
- switched off (OFF) 1 trip indicator green)
- Product Name:
- PowerPact H
- Net Weight:
- 2.2 kg
- [Ics] Rated Service Breaking Capacity:
- 65 kA 220/240 V AC 50/60 Hz IEC 60947-2 || 35 kA 380/440/415 V AC 50/60 Hz IEC 60947-2 || 18 kA 500/525 V AC 50/60 Hz IEC 60947-2 || 20 kA 250 V DC IEC 60947-2 || 20 kA 500 V DC IEC 60947-2
- Mounting Mode:
- unit mount lug)
- Poles Description:
- 3P
- Terminal Identifier:
- AL150HD
- Breaking Capacity Code:
- J
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Height:
- 163 mm
- Awg Gauge:
- AWG 14...AWG 3/0 aluminium/copper terminal
- [Ui] Rated Insulation Voltage:
- 750 V IEC 60947-2
- Trip Unit Technology:
- thermal-magnetic
- Ambient Air Temperature For Operation:
- -2-70 °C
- Mercury Free:
- Yes
- Suitability For Isolation:
- yes IEC 60947-2
- Ambient Air Temperature For Storage:
- -50-85 °C
- [Uimp] Rated Impulse Withstand Voltage:
- 8 kV IEC 60947-2
- Electrical Connection:
- lugs, line || lugs, load
- Depth:
- 86 mm
- Number Of Slots:
- 2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
- Wire Stripping Length:
- 16 mm
- Operating Altitude:
- < 6561.68 ft (2000 m) without derating || 5000 m with derating
- China Rohs Regulation:
- Product out of China RoHS scope. Substance declaration for your information.
- Warranty:
- 18 months
- Color:
- Black
- Magnetic Hold Current:
- 800 A
- Accessory / Separate Part Type:
- shunt trip 110...130 V AC compartment
- Pvc Free:
- Yes
- Control Type:
- toggle
- Magnetic Tripping Current:
- 1450-1450 A
- Device Application:
- distribution
- Continuous Current Rating:
- 0.8
- [Ue] Rated Operational Voltage:
- 690 V AC 50/60 Hz IEC 60947-3
- Ip Degree Of Protection:
- front cover IP40 IEC 60529
- Standards:
- UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
- Breaking Capacity:
- 100 kA 240 V AC 50/60 Hz UL 489 || 65 kA 480 V AC 50/60 Hz UL 489 || 25 kA 600 V AC 50/60 Hz UL 489 || 20 kA 250 V DC UL 489
- Utilisation Category:
- category A
- Mounting Support:
- lug
- Product Certifications:
- UL || CSA || NOM
- Tightening Torque:
- 5-5 N.m 2.5-6 mm² (AWG 14...AWG 10) || 14-14 N.m 10-95 mm² (AWG 8...AWG 3/0)
- Protected Poles Description:
- 3t
- Quantity Per Set:
- 1
- Rohs Exemption Information:
- Yes
- Quality Labels:
- CE
- Eu Rohs Directive:
- Compliant with Exemptions
