Schneider Electric HJP36020 Circuit breaker, PowerPacT H, 20A, 3 pole, 600VAC, 25kA, lugs, thermal magnetic, 80%

Schneider Electric HJP36020 Circuit breaker, PowerPacT H, 20A, 3 pole, 600VAC, 25kA, lugs, thermal magnetic, 80%

Schneider Electric
SKU:
HJP36020
$1,949.00
(No reviews yet) Write a Review
Condition:
New
Current Stock:
Description
PowerPacT H-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT H-Frame circuit breakers are available with either thermal magnetic or Micrologic electronic trip protection units. This PowerPacT H-Frame circuit breaker provides thermal magnetic circuit protection with a breaking capacity of 25kA at 600VAC. All PowerPacT H-Frame circuit breakers are equipped with dual-break rotating contacts that reduce the amount of peak current during a short circuit fault. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT H circuit breakers are available in 2 and 3-pole unit mount and I-Line constructions. This breaker has terminal nuts on the line side and lugs on the load side. This PowerPacT H, 20A, 3 pole, circuit breaker has a breaking capacity of 25kA at 600VAC. This circuit breaker has a continuous current rating of 80%. PowerPacT H circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
Additional Information
Magnetic Tripping Current:
750-750 A
Circularity Profile:
ENVEOLI2206027EN
Wire Stripping Length:
16 mm
Warranty:
18 months
Operating Altitude:
< 6561.68 ft (2000 m) without derating || 5000 m with derating
Depth:
86 mm
Product Certifications:
UL || CSA || NOM
Net Weight:
2.2 kg
Control Type:
toggle
Ambient Air Temperature For Operation:
-25-70°C
Eu Rohs Directive:
Compliant with Exemptions
[Uimp] Rated Impulse Withstand Voltage:
8 kV IEC 60947-2
[Ui] Rated Insulation Voltage:
750 V IEC 60947-2
Breaking Capacity:
100 kA 240 V AC 50/60 Hz UL 489 || 65 kA 480 V AC 50/60 Hz UL 489 || 25 kA 600 V AC 50/60 Hz UL 489 || 20 kA 250 V DC UL 489
Communication Interface:
Modbus || Ethernet
[Ue] Rated Operational Voltage:
690 V AC 50/60 Hz IEC 60947-3
Environmental Disclosure:
ENVPEP2206027EN
Utilisation Category:
category A
Device Application:
distribution
Pvc Free:
Yes
Quantity Per Set:
1
Protected Poles Description:
3t
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Country of Origin:
United States
Color:
Black
Network Frequency:
50/60 Hz
Terminal Identifier:
AL150HD
[Ics] Rated Service Breaking Capacity:
65 kA 220/240 V AC 50/60 Hz IEC 60947-2 || 35 kA 380/440/415 V AC 50/60 Hz IEC 60947-2 || 18 kA 500/525 V AC 50/60 Hz IEC 60947-2 || 20 kA 250 V DC IEC 60947-2 || 20 kA 500 V DC IEC 60947-2
Continuous Current Rating:
0.8
Rohs Exemption Information:
Yes
Ip Degree Of Protection:
front cover IP40 IEC 60529
Mercury Free:
Yes
Quality Labels:
CE
Suitability For Isolation:
yes IEC 60947-2
Standards:
UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
Line Rated Current:
20-20 A
Range:
PowerPact
Trip Unit Technology:
thermal-magnetic
Mounting Mode:
unit mount lug)
California Proposition 65:
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
Product Or Component Type:
circuit breaker
Awg Gauge:
AWG 14...AWG 3/0 aluminium/copper terminal
Local Signaling:
switched off (OFF) 1 trip indicator green)
Width:
104 mm
Number Of Slots:
2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
Mounting Support:
lug
Pollution Degree:
3 IEC 60947-1
Breaking Capacity Code:
J
