Schneider Electric HMIDT75X 15W Touch Extreme Display Fwxga

(No reviews yet) Write a Review

Write a Review

Schneider Electric HMIDT75X 15W Touch Extreme Display Fwxga

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

HMIDT75X

UPC:

3606489747961

MPN:

Condition:

New

Touch Panel:

single touch analogue resistive

Operating Altitude:

6561.68 ft (2000 m)

Luminance:

1000 cd/m²

Display Type:

colour TFT LCD

Pixel Resolution:

1366 x 768

Vibration Resistance:

7 mm constant amplitude 5-9 Hz) IEC 61131-2 || 9.8 m/s² 9-150 Hz) IEC 61131-2

Product Certifications:

KC || CE || RCM || EAC || ATEX zone 2/22 || IEC-Ex || UL || CSA || UKCA || UKEX

Display Colour:

262144 colors

Ip Degree Of Protection:

IP66f || IP67f || front panel Type 4X

Ambient Air Temperature For Operation:

-20-60 °C IEC 61131-2

Display Size:

15.6 inch

Cut-Out Dimensions:

394 (+ 1/- 0) x 250 (+ 1/- 0) mm

[Us] Rated Supply Voltage:

12 V DC power supply

Sustainable Offer Status:

Green Premium product

Height:

264 mm

Pollution Degree:

2

Display Resolution:

1366 x 768 pixels FWXGA

Supply Voltage Limits:

10.8-28.8 V

California Proposition 65:

WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Depth:

68 mm

Product Or Component Type:

eXtreme touchscreen panel

Rohs Exemption Information:

Yes

China Rohs Regulation:

X

Relative Humidity:

10-90 % non-condensing

Type Of Cooling:

natural convection

Shock Resistance:

392 m/s²IEC 61131-2

Power Consumption In W:

12.5 W

Ambient Air Temperature For Storage:

-20-60 °C

Electromagnetic Compatibility:

electrostatic discharge immunity test level 3 conforming to IEC 61000-4-2

Reach Regulation:

Reference contains Substances of Very High Concern above the threshold

Terminal Type:

touchscreen display

Range Of Product:

Harmony GTUX

Circularity Profile:

ENVEOLI1402016EN

Aspect Ratio:

0.16875

Touchscreen Resolution:

1024 x 1024

Eu Rohs Directive:

Pro-active compliance (Product out of EU RoHS legal scope)

Standards:

UL 61010 || UL 121201 || CSA C22.2 No 213 || CSA C22.2 No 61010-1 || IEC 61132-2

Inrush Current:

30 A

Environmental Disclosure:

ENVPEP1402016EN

Width:

408 mm

Net Weight:

4.8 kg

Environmental Characteristic:

corrosive gas free || UV resistant

Weee:

The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.

Brochure:

View

Catalog:

View

Datasheet:

View
