Schneider Electric HMIG5U21 Open Box Universal Panel
Schneider Electric
$2,192.10
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
This product is part of the Harmony GTU range, an offer of High performance IoT-ready modular HMI panels from 7 inch to 19 inch (Width) screen. The open box features Intel X86 1.33GHz processor and 32GB CFast card data storage, suits for universal panel. It is designed with backup memory of NVRAM 512kB and internal memory of RAM 4GB. This open box supports Windows 10 IoT Enterprise 2019 LTSC 32bit operating system. It is equipped with 10BASE-T/100BASE-TX/1000BASE-T Ethernet port. Communication port protocols are Modbus, Modbus TCP/IP and Uni-Telway. Its dimensions are 188mm (width) x 45mm (depth) x 131mm (height) and weighs 0.9kg. This product is not installed with HMI software. This product is certified by ATEX, IECEx, CE, CULus, IEC, CUL, DNV-GL, RCM and EAC. It meets CSA C22.2 No 142, ANSI/ISA 12-12-01, UL 508, Class I division 2 CSA C22.2 No 213 and IEC 61132-2 standards. Harmony GTU (formerly known as Magelis GTU) are universal panels that include smartphone-like interface and Wireless technology. They offer unmatched comfort of use with no compromise on performance and openness.
- Rohs Exemption Information:
- Yes
- China Rohs Regulation:
- X
- Processor Name:
- Intel X86 1.33 GHz
- Environmental Disclosure:
- ENVPEP1403023EN
- Net Weight:
- 0.9 kg
- Number Of Slots:
- 1 slot(s) for SD card || 2 slot(s) for Cfast card
- Realtime Clock:
- built-in
- Product Or Component Type:
- base unit
- Range Compatibility:
- Harmony GTU
- Range Of Product:
- Harmony GTU
- Device Short Name:
- Open Box
- Height:
- 131 mm
- Weee:
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
- Type Of Cooling:
- natural convection
- Relative Humidity:
- 10-90 % non-condensing
- Pollution Degree:
- 2 EN 61131-2 Ed.3
- Sustainable Offer Status:
- Green Premium product
- Standards:
- CSA C22.2 No 142 || ANSI/ISA 12-12-01 || UL 508 || class I division 2 CSA C22.2 No 213 || IEC 61132-2
- Mercury Free:
- Yes
- [Us] Rated Supply Voltage:
- 12...24 V DC power supply
- Memory Description:
- 512 KB NVRAM backup memory || 4 GB RAM internal
- Width:
- 188 mm
- Operating System:
- Windows 10 IoT Enterprise 32bit
- Communication Port Protocol:
- Modbus || Modbus TCP/IP || Uni-Telway
- Ambient Air Temperature For Storage:
- -20-60 °C
- Integrated Connection Type:
- Ethernet TCP/IP 2 RJ45 || COM1 serial link RJ45 RS485 110...115200 bit/s || COM2 serial link SUB-D 9 RS232C/RS422/RS485 110...115200 bit/s || auxiliary port terminal block || USB 2.0 port mini B USB || DVI-D video port DVI-D || microphone mini-jack |
- Port Ethernet:
- 10BASE-T/100BASE-TX/1000BASE-T
- Ambient Air Temperature For Operation:
- 0-60 °C
- Circularity Profile:
- ENVEOLI1403023EN
- Data Storage Equipment:
- 32 GB CFast card
- Depth:
- 45 mm
- Local Signalling:
- , multi-colour LEDstatus
- Software Package:
- Internet Explorer || .NET framework 4.0 || multimedia player
- Product Certifications:
- CE || cULus || ATEX || IEC-Ex || RCM || DNV-GL || KC || cUL || EAC || UKCA || UKEX
- Electromagnetic Compatibility:
- electrostatic discharge immunity test level 3 conforming to EN/IEC 61000-4-2
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Vibration Resistance:
- 9.8 m/s² 9-150 Hz) EN/IEC 61131-2
- Catalog:
- View
- Datasheet:
- View
