Schneider Electric LC1G225KUEN Contactor, high power, TeSys Giga, standard version, 3 pole/NO, AC-3 <=440V 225A, 100-250VAC/DC coil

(No reviews yet) Write a Review
SKU:
LC1G225KUEN
MPN:
LC1G225KUEN
Condition:
New
Permissible Ambient Air Temperature Around The Device:
-40-70°C at Uc
Halogen Content Performance:
Halogen free plastic parts product
Power Dissipation Per Pole:
20 W AC-1 - Ith 330 A || 8 W AC-3 - Ith 225 A
Ambient Air Temperature For Storage:
-60-80°C
Net Weight:
3.6 kg
Standards:
EN/IEC 60947-4-1 || EN/IEC 60947-5-1 || UL 60947-4-1 || CSA C22.2 No 60947-4-1 || JIS C8201-4-1 || JIS C8201-5-1 || IEC 60335-1:Clause 30.2 || IEC 60335-2-40:Annex JJ || UL 60335-1 || UL 60335-2-40:Annex JJ
Sustainable Offer Status:
Green Premium product
Auxiliary Contact Composition:
1 NO + 1 NC
[Ie] Rated Operational Current:
330 A (at <40°C) at <= 1000 V AC-1 || 225 A (at <60°C) at <= 440 V AC-3
Color:
dark grey
Maximum Operating Rate:
600 cyc/h AC-3 || 600 cyc/h AC-3e || 300 cyc/h AC-1 || 150 cyc/h AC-4
Maximum Horse Power Rating:
60 hp at 200/208 V 60 Hz || 75 hp at 230/240 V 60 Hz || 150 hp at 460/480 V 60 Hz || 150 hp at 575/600 V 60 Hz
Environmental Disclosure:
ENVPEP2105013
Depth:
193 mm
Product Or Component Type:
contactor
Connection Pitch:
35 mm
Compatibility Code:
LC1G
[Ui] Rated Insulation Voltage:
1000 V
Operating Time:
40...70 ms closing || 15...50 ms opening
Country of Origin:
United States
Device Short Name:
LC1G
Irms Rated Making Capacity:
2720 A at 440 V
Contactor Application:
power switching || motor control
Ambient Air Temperature For Operation:
-25-60°C
[Ith] Conventional Free Air Thermal Current:
330 A (at 40°C)
[Ue] Rated Operational Voltage:
<= 1000 V AC 50/60 Hz || <= 460 V DC
Height:
193 mm
Inrush Power In W:
380 W
Utilisation Category:
AC-1 || AC-3 || AC-3e || AC-4 || AC-5a || AC-5b || AC-6a || AC-6b || AC-8a || AC-8b || DC-1 || DC-3 || DC-5
Poles Description:
3P
Pole Contact Composition:
3 NO
Range:
TeSys
Mercury Free:
Yes
Overvoltage Category:
III
[Uimp] Rated Impulse Withstand Voltage:
8 kV
Inrush Power In Va:
540-540 VA
Protective Treatment:
TH
Hold-In Power Consumption In Va:
12.4-12.4 VA
Mechanical Durability:
8 Mcycles
Circularity Profile:
ENVEOLI2105013
[Icw] Rated Short-Time Withstand Current:
1.8 kA - 10 s || 1.0 kA - 30 s || 0.85 kA - 1 min || 0.56 kA - 3 min || 0.44 kA - 10 min
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Range Of Product:
TeSys Giga
Mechanical Robustness:
vibrations 5-300 Hz 2 gn contactor open || vibrations 5-300 Hz 4 gn contactor closed || shocks 10 gn 11 ms contactor open || shocks 15 gn 11 ms contactor closed
Associated Fuse Rating:
250 A aM at <= 440 V for motor || 200 A aM at <= 690 V for motor || 400 A gG at <= 690 V
Eu Rohs Directive:
Compliant with Exemptions
Motor Power Kw:
55 kW at 230 V AC 50/60 Hz (AC-3e) || 110 kW at 400 V AC 50/60 Hz (AC-3e) || 110 kW at 415 V AC 50/60 Hz (AC-3e) || 132 kW at 440 V AC 50/60 Hz (AC-3e) || 132 kW at 500 V AC 50/60 Hz (AC-3e) || 160 kW at 690 V AC 50/60 Hz (AC-3e) || 132 kW at 1000 V
Rohs Exemption Information:
Yes
$1,155.00

Description

TeSys Giga high power contactor, 3 poles (3 NO) for category AC-3 applications up to 225A 132kW@440V. It provides a 100-250V AC/DC wide band low consumption electronic coil and embedded highly reliability 1NO+1NC auxiliary contact block (17V 1mA). Designed for demanding applications with maximum operating rates up to 600 cycles per hour and environments until 60°C. It procures high reliability and durability with 5 Mcycles mechanical durability. Local Contact Wear Diagnosis (CWD) as standard function, continuous monitoring with healthy and alarm indicators. It is possibility to replace switching module (main contacts), enhancement contactor life. Contactor can be fixed in all quadrants, maintenance without removing cables/busbars, and OLR could be directly mounted below contactor. To be used with power connection by bolted connection and control connections by spring terminals, accessible from front for easy and quick replacement. It provides IP2x protection in Front face with shrouds conforming to IEC 60529 and VDE 0106. It can cover -25°C to 60°C operation ambient air temperature and directly mounted on plate, No derating up to 3000m altitude. The dimension is 255mm x 108mm x 175mm (H x W x D), compact size enables panel space savings. Multi standards certified(CE,CB,CCC,cULus,EAC,KC,RCM,Marine) and Green Premium compliant (RoHs/Reach). Unique QR code provides quick access to complete product data.
