Schneider Electric LV426846 Coil Mx Ac 380-415 V 50 Hz

Schneider Electric LV426846 Coil Mx Ac 380-415 V 50 Hz

Schneider Electric
SKU:
LV426846
|
UPC:
3.60649E+12
Availability:
Contact us to confirm availability and lead times.
$620.00
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
This standard MX shunt trip is used on Compact NSXm and PowerPact B devices. This auxiliary is used for emergency off or failsafe remote opening applications. It is a one click spring type auxiliary for quick and easy installation, visible from the front face of the device. This MX auxiliary has a 380/415 VAC 50 Hz or 440/480 VAC 60 Hz rated voltage. It trips the circuit breaker when the control voltage rises above 70% of its rated value. It complies with IEC 60947-2 standard. Compact NSXm and PowerPact B embed either 1 MN or 1 MX coil.
Additional Information
Circularity Profile:
ENVEOLI2311043EN
Eu Rohs Directive:
Compliant with Exemptions
Device Application:
control
Auxiliary Connection Terminal:
spring
Control Signal Type:
impulse || maintained
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Mercury Free:
Yes
Sustainable Offer Status:
Green Premium product
Environmental Disclosure:
ENVPEP2311043EN
Range Of Product:
ComPacT NSXm new generation
Voltage Release Type:
opening coil || shunt trip release
Rohs Exemption Information:
Yes
Response Time:
< 50 ms
Control Type:
standard
Product Or Component Type:
voltage release
California Proposition 65:
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
Weee:
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Range Compatibility:
ComPact ComPacT NSXm new generation || ComPact ComPact NSXm || PowerPact PowerPact B
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Impulse Duration:
>= 20 ms
Range:
ComPact
Device Short Name:
MX
Threshold Tripping Voltage:
0.7 Un opening
[Uc] Control Circuit Voltage:
380...415 V AC 50 Hz || 440...480 V AC 60 Hz
