Schneider Electric LXM28AU01M3X Lexium28 Can Io Drive 1/3Ph 230V 100W

(No reviews yet) Write a Review

Write a Review

Schneider Electric LXM28AU01M3X Lexium28 Can Io Drive 1/3Ph 230V 100W

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

LXM28AU01M3X

UPC:

3.60648E+12

MPN:

Condition:

New

Communication Interface:

CANopen, Integrated || CANmotion, Integrated

Type Of Cable:

shielded motor cable 0-55 °C) copper

Continuous Output Current:

0.9 A 16 kHz

Electrical Isolation:

between power and control

Shock Resistance:

10 gn, type I IEC 60721-3-3

Reach Free Of Svhc:

Yes

Electromagnetic Compatibility:

conducted emission - test level: level 3 category C3 conforming to IEC 61800-3

Continuous Power:

100 W 220 V

Maximum Leakage Current:

1.3 mA

Mercury Free:

Yes

Discrete Input Voltage:

24 V DC logic

Supply Voltage Limits:

200-255 V three phase || 170-255 V single phase

Electrical Connection:

spring terminal 0.82...1 mm², AWG 18 L1-L2) || spring terminal 0.82...1 mm², AWG 18 R, S, T) || spring terminal 0.82...1 mm², AWG 18 U, V, W, PE) || spring terminal 0.82...1 mm², AWG 18 PA/+, PBe)

Operating Position:

vertical

Physical Interface:

RS485 Modbus Serial line slave

[Us] Rated Supply Voltage:

200...240 V - 10...15 %)three phase || 200...240 V - 20...15 %)single phase

Depth:

146 mm

Ambient Air Temperature For Operation:

0-55 °C

Connector Type:

RJ45 CN4)CANopen, CANmotion

Phase:

three phase || single phase

Output Current 3S Peak:

2.7 A 220 V

Output Current 3S Peak 3:

2.7 A 220 V

Protection Type:

against reverse polarity inputs signal || against short-circuits outputs signal || overcurrent motor || overvoltage motor || undervoltage motor || overheating motor || overload motor || overspeed motor

Width:

55 mm

Control Signal Type:

servo motor encoder feedback CN2

Net Weight:

1 kg

Marking:

CSA || cULus || CE

Nominal Power:

0.1 kW 220 V 16 kHz

Product Compatibility:

servo motor BCH2 40 mm, 2 100 W

Eu Rohs Directive:

Pro-active compliance (Product out of EU RoHS legal scope)

Product Certifications:

CE || CSA || cULus

Switching Frequency:

16 kHz

Sustainable Offer Status:

Green Premium product

Safety Level:

SIL 2 IEC 61800-5-2 2007 || SIL 2 IEC 61508-1 2010 || PL d/category 3 ISO 13849-1 2008 || SIL 2 ISO 13849-1 2009/AC || SIL 2 IEC 60204-1 2006 || SIL 2 IEC 60204-1 2009/A1 || SIL 2 IEC 60204-1 2010/AC || SIL 2 IEC 62061 2012

China Rohs Regulation:

X

Analogue Input Type:

V_REF voltage analog input - 10...10 V 10 kOhm 14 bits || T_REF voltage analog input

Status Led:

1 LED (Red) charge || 1 LED (Green) RUN || 1 LED (Red) error

Transmission Rate:

250 kbit/s 100-250 m CANopen, CANmotion || 500 kbit/s 4-100 m CANopen, CANmotion || 1 Mbit/s 4-4 m CANopen, CANmotion

Weee:

The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.

Supply Frequency:

50/60 Hz - 5...5 %

Operating Altitude:

<= 3280.84 ft (1000 m) without derating || > 3280.84...6561.68 ft (> 1000...2000 m) 1 % per 100 m

Number Of Addresses:

1-127 CANopen, CANmotion

Signalling Function:

servo status and fault codes five 7-segment display units

Ip Degree Of Protection:

IP20

Discrete Input Logic:

positive or negative CN1)

Discrete Output Number:

5 logic output CN1)12...24 V DC || 1 pulse train output (PTO) CN1)

Reach Regulation:

Free of Substances of Very High Concern above the threshold

Discrete Output Logic:

positive or negative CN1)

Product Or Component Type:

motion servo drive

Device Short Name:

LXM28A

Absolute Accuracy Error:

0.001

Rohs Exemption Information:

Yes

Analogue Input Number:

2

Format Of The Drive:

compact housing

Overvoltage Category:

III

Method Of Access:

slave

Discrete Output Voltage:

12...24 V DC

Output Voltage:

<= power supply voltage

Pvc Free:

Yes

Environmental Disclosure:

ENVPEP1409001EN

Circularity Profile:

ENVEOLI1409001EN

California Proposition 65:

WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Safety Function:

STO (safe torque off), Integrated

Output Current 3S Peak 2:

2.7 A 220 V

Emc Filter:

without EMC filter

Ambient Air Temperature For Storage:

-25-65 °C

Line Current:

1.2 A 239.2 % 220 V, single phase || 1.2 A 212.7 % 220 V, three phase

Discrete Input Number:

8 programmable CN1) || 1 pulse train input (PTI) CN1) || 2 fast capture CN1) || 1 safety function STO CN9)

Height:

150 mm

Standards:

IEC 61800-5-1

Network Frequency:

47.5...63 Hz

Relative Humidity:

5-95 % without condensation

Vibration Resistance:

3M4 3 mm 9-200 Hz)IEC 60721-3-3

Range Of Product:

Lexium 28

Type Of Cooling:

natural convection
