Schneider Electric LXM28AU02M3X Lexium28 Can Io Drive 1/3Ph 230V 200W

(No reviews yet) Write a Review

Write a Review

Schneider Electric LXM28AU02M3X Lexium28 Can Io Drive 1/3Ph 230V 200W

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

LXM28AU02M3X

UPC:

3.60648E+12

MPN:

Condition:

New

Supply Voltage Limits:

200-255 V three phase || 170-255 V single phase

Depth:

146 mm

Range Of Product:

Lexium 28

Network Frequency:

47.5...63 Hz

Shock Resistance:

10 gn, type I IEC 60721-3-3

Continuous Power:

200 W 220 V

Switching Frequency:

16 kHz

Vibration Resistance:

3M4 3 mm 9-200 Hz)IEC 60721-3-3

Overvoltage Category:

III

Output Voltage:

<= power supply voltage

Operating Position:

vertical

Analogue Input Number:

2

[Us] Rated Supply Voltage:

200...240 V - 10...15 %)three phase || 200...240 V - 20...15 %)single phase

Environmental Disclosure:

ENVPEP1409001EN

Product Or Component Type:

motion servo drive

Ip Degree Of Protection:

IP20

Discrete Output Logic:

positive or negative CN1)

Electrical Connection:

spring terminal 0.82...1 mm², AWG 18 L1-L2) || spring terminal 0.82...1 mm², AWG 18 R, S, T) || spring terminal 0.82...1 mm², AWG 18 U, V, W, PE) || spring terminal 0.82...1 mm², AWG 18 PA/+, PBe)

Output Current 3S Peak:

4.5 A 220 V

Status Led:

1 LED (Red) charge || 1 LED (Green) RUN || 1 LED (Red) error

Operating Altitude:

<= 3280.84 ft (1000 m) without derating || > 3280.84...6561.68 ft (> 1000...2000 m) 1 % per 100 m

California Proposition 65:

WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Output Current 3S Peak 2:

4.5 A 220 V

Safety Level:

SIL 2 IEC 61800-5-2 2007 || SIL 2 IEC 61508-1 2010 || PL d/category 3 ISO 13849-1 2008 || SIL 2 ISO 13849-1 2009/AC || SIL 2 IEC 60204-1 2006 || SIL 2 IEC 60204-1 2009/A1 || SIL 2 IEC 60204-1 2010/AC || SIL 2 IEC 62061 2012

Nominal Power:

0.2 kW 220 V 16 kHz

Product Certifications:

cULus || CSA || CE

Weee:

The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.

Control Signal Type:

servo motor encoder feedback CN2

Relative Humidity:

5-95 % without condensation

Marking:

CSA || cULus || CE

Rohs Exemption Information:

Yes

Maximum Leakage Current:

1.3 mA

Sustainable Offer Status:

Green Premium product

Line Current:

2.4 A 226.8 % 220 V, single phase || 2.4 A 200.7 % 220 V, three phase

Width:

55 mm

Format Of The Drive:

compact housing

Protection Type:

against reverse polarity inputs signal || against short-circuits outputs signal || overcurrent motor || overvoltage motor || undervoltage motor || overheating motor || overload motor || overspeed motor

Ambient Air Temperature For Storage:

-25-65 °C

Emc Filter:

without EMC filter

Product Compatibility:

servo motor BCH2 60 mm, 1 200 W

Electromagnetic Compatibility:

conducted emission - test level: level 3 category C3 conforming to IEC 61800-3

Type Of Cooling:

natural convection

Connector Type:

RJ45 CN4)CANopen, CANmotion

Ambient Air Temperature For Operation:

0-55 °C

Height:

150 mm

Circularity Profile:

ENVEOLI1409001EN

Method Of Access:

slave

Signalling Function:

servo status and fault codes five 7-segment display units

Discrete Input Voltage:

24 V DC logic

Discrete Output Voltage:

12...24 V DC

Supply Frequency:

50/60 Hz - 5...5 %

Reach Free Of Svhc:

Yes

Discrete Output Number:

5 logic output CN1)12...24 V DC || 1 pulse train output (PTO) CN1)

Phase:

three phase || single phase

Safety Function:

STO (safe torque off), Integrated

Physical Interface:

RS485 Modbus Serial line slave

Reach Regulation:

Free of Substances of Very High Concern above the threshold

Discrete Input Number:

8 programmable CN1) || 1 pulse train input (PTI) CN1) || 2 fast capture CN1) || 1 safety function STO CN9)

Communication Interface:

CANopen, Integrated || CANmotion, Integrated

Pvc Free:

Yes

Absolute Accuracy Error:

0.001

Type Of Cable:

shielded motor cable 0-55 °C) copper

Electrical Isolation:

between power and control

Net Weight:

1 kg

Eu Rohs Directive:

Pro-active compliance (Product out of EU RoHS legal scope)

Output Current 3S Peak 3:

4.5 A 220 V

Transmission Rate:

250 kbit/s 100-250 m CANopen, CANmotion || 500 kbit/s 4-100 m CANopen, CANmotion || 1 Mbit/s 4-4 m CANopen, CANmotion

Device Short Name:

LXM28A

Standards:

IEC 61800-5-1

China Rohs Regulation:

X

Mercury Free:

Yes

Discrete Input Logic:

positive or negative CN1)

Number Of Addresses:

1-127 CANopen, CANmotion

Analogue Input Type:

V_REF voltage analog input - 10...10 V 10 kOhm 14 bits || T_REF voltage analog input

Continuous Output Current:

1.5 A 16 kHz
