Schneider Electric LXM28AU45M3X Lexium28 Can Io Drive 3Ph 230V 4,5Kw
SKU:
LXM28AU45M3X
UPC:
3606480711848
MPN:
Condition:
New
Discrete Input Logic:
positive or negative CN1)
Network Frequency:
47.5...63 Hz
Format Of The Drive:
compact housing
Product Certifications:
cULus || CSA || CE
Output Current 3S Peak 2:
61 A 220 V
Continuous Output Current:
22.9 A 8 kHz
Reach Free Of Svhc:
Yes
Overvoltage Category:
III
Mercury Free:
Yes
Continuous Power:
4500 W 220 V
Standards:
IEC 61800-5-1
Status Led:
1 LED (Red) charge || 1 LED (Green) RUN || 1 LED (Red) error
Operating Position:
vertical
Maximum Leakage Current:
1.55 mA
Ambient Air Temperature For Operation:
0-55 °C
Connector Type:
RJ45 CN4)CANopen, CANmotion
Circularity Profile:
ENVEOLI1409001EN
Electrical Isolation:
between power and control
Depth:
186 mm
Physical Interface:
RS485 Modbus Serial line slave
Line Current:
17.9 A 147.1 % 220 V, three phase
Weee:
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Output Current 3S Peak 3:
61 A 220 V
Operating Altitude:
<= 3280.84 ft (1000 m) without derating || > 3280.84...6561.68 ft (> 1000...2000 m) 1 % per 100 m
Height:
234 mm
Ambient Air Temperature For Storage:
-25-65 °C
Discrete Input Voltage:
24 V DC logic
China Rohs Regulation:
X
Rohs Exemption Information:
Yes
Vibration Resistance:
3M4 3 mm 9-200 Hz)IEC 60721-3-3
Supply Voltage Limits:
200-255 V three phase
Product Or Component Type:
motion servo drive
Switching Frequency:
8 kHz
Discrete Output Voltage:
12...24 V DC
Signalling Function:
servo status and fault codes five 7-segment display units
Device Short Name:
LXM28A
Reach Regulation:
Free of Substances of Very High Concern above the threshold
Emc Filter:
without EMC filter
California Proposition 65:
WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Pvc Free:
Yes
Output Voltage:
<= power supply voltage
Discrete Input Number:
8 programmable CN1) || 1 pulse train input (PTI) CN1) || 2 fast capture CN1) || 1 safety function STO CN9)
Eu Rohs Directive:
Pro-active compliance (Product out of EU RoHS legal scope)
Phase:
three phase
Type Of Cable:
shielded motor cable 0-55 °C) copper
Analogue Input Type:
V_REF voltage analog input - 10...10 V 10 kOhm 14 bits || T_REF voltage analog input
Electromagnetic Compatibility:
conducted emission - test level: level 3 category C3 conforming to IEC 61800-3
Safety Level:
SIL 2 IEC 61800-5-2 2007 || SIL 2 IEC 61508-1 2010 || PL d/category 3 ISO 13849-1 2008 || SIL 2 ISO 13849-1 2009/AC || SIL 2 IEC 60204-1 2006 || SIL 2 IEC 60204-1 2009/A1 || SIL 2 IEC 60204-1 2010/AC || SIL 2 IEC 62061 2012
Sustainable Offer Status:
Green Premium product
Communication Interface:
CANopen, Integrated || CANmotion, Integrated
[Us] Rated Supply Voltage:
200...240 V - 10...15 %)three phase
Absolute Accuracy Error:
0.001
Product Compatibility:
servo motor BCH2 180 mm, 3 4500 W || servo motor BCH2 180 mm, 2 3500 W
Marking:
cULus || CSA || CE
Safety Function:
STO (safe torque off), Integrated
Method Of Access:
slave
Discrete Output Number:
5 logic output CN1)12...24 V DC || 1 pulse train output (PTO) CN1)
Width:
116 mm
Nominal Power:
4.5 kW 220 V 8 kHz
Discrete Output Logic:
positive or negative CN1)
Range Of Product:
Lexium 28
Protection Type:
against reverse polarity inputs signal || against short-circuits outputs signal || overcurrent motor || overvoltage motor || undervoltage motor || overheating motor || overload motor || overspeed motor
Number Of Addresses:
1-127 CANopen, CANmotion
Net Weight:
3.2 kg
Analogue Input Number:
2
Supply Frequency:
50/60 Hz - 5...5 %
Relative Humidity:
5-95 % without condensation
Electrical Connection:
spring terminal 6 mm², AWG 10 L1-L2) || spring terminal 6 mm², AWG 10 R, S, T) || spring terminal 6 mm², AWG 10 U, V, W, PE) || spring terminal 6 mm², AWG 10 PA/+, PBe)
Ip Degree Of Protection:
IP20
Control Signal Type:
servo motor encoder feedback CN2
Transmission Rate:
250 kbit/s 100-250 m CANopen, CANmotion || 500 kbit/s 4-100 m CANopen, CANmotion || 1 Mbit/s 4-4 m CANopen, CANmotion
