Schneider Electric M9F14316 Multi9 C60H 3P C 16A 15Ka 415V Mcb

(No reviews yet) Write a Review

Write a Review

Schneider Electric M9F14316 Multi9 C60H 3P C 16A 15Ka 415V Mcb

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

M9F14316

UPC:

3606480577307

MPN:

Condition:

New

Depth:

72 mm

Net Weight:

0.36 kg

9 Mm Pitches:

6

Product Or Component Type:

miniature circuit-breaker

Line Rated Current:

16 A 50 °C EN/IEC 60947-2

Ip Degree Of Protection:

IP20 conforming to IEC 60529 || IP40 (modular enclosure) conforming to IEC 60529

Provision For Padlocking:

padlockable

Mounting Mode:

clip-on

Network Frequency:

50/60 Hz

Eu Rohs Directive:

Compliant with Exemptions

Poles Description:

3P

Heat Dissipation:

7.5-7.5 W 415 V - 16 A

Suitability For Isolation:

yes EN/IEC 60947-2

Mechanical Durability:

20000 cycles

[Ics] Rated Service Breaking Capacity:

15 kA 50 % EN/IEC 60947-2 - 240 V AC 50/60 Hz || 7.5 kA 50 % EN/IEC 60947-2 - 415 V AC 50/60 Hz || 5 kA 50 % EN/IEC 60947-2 - 440 V AC 50/60 Hz || 40 kA 100 % EN/IEC 60947-2 - <= 125 V DC

Wire Stripping Length:

14 mm for top or bottom connection

Device Short Name:

C60H

Magnetic Tripping Limit:

8.5 x In +/- 20 % AC || 12 x In +/- 20 % DC

Environmental Disclosure:

ENVPEP1304004EN

Sustainable Offer Status:

Green Premium product

Pollution Degree:

3 EN/IEC 60947-2

Contact Position Indicator:

yes

Number Of Protected Poles:

3

Relative Humidity:

95-95 % 55-55 °C

Breaking Capacity:

40 kA Icu <= 125 V DC EN/IEC 60947-2 || 30 kA Icu 240 V AC 50/60 Hz between phases EN/IEC 60947-2 || 15 kA Icu 415 V AC 50/60 Hz between phases EN/IEC 60947-2 || 10 kA Icu 440 V AC 50/60 Hz between phases EN/IEC 60947-2

Weee:

The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.

Device Application:

distribution

Tropicalisation:

2 IEC 60068-1

Mercury Free:

Yes

Earth-Leakage Protection:

separate block

Standards:

EN/IEC 60947-2

Product Certifications:

EAC || CCC

Circularity Profile:

N/A

[Ue] Rated Operational Voltage:

240 V AC 50/60 Hz between phases || 415 V AC 50/60 Hz between phases || 440 V AC 50/60 Hz between phases || <= 125 V DC

[Ui] Rated Insulation Voltage:

500 V AC 50/60 Hz EN/IEC 60947-2

Curve Code:

C

Ambient Air Temperature For Storage:

-40-80 °C

Range:

Multi9

[Uimp] Rated Impulse Withstand Voltage:

6 kVEN/IEC 60947-2

Ambient Air Temperature For Operation:

-30-70 °C

Reach Regulation:

Reference contains Substances of Very High Concern above the threshold

Overvoltage Category:

IV

Mounting Support:

DIN rail

Tightening Torque:

2-2 N.m top or bottom

Halogen Content Performance:

Halogen free plastic parts & cables product

Network Type:

AC || DC

China Rohs Regulation:

Product out of China RoHS scope. Substance declaration for your information.

Electrical Durability:

10000 cycles

Utilisation Category:

category A EN/IEC 60947-2

Height:

81 mm

Width:

54 mm

Color:

Gray

Product Name:

Multi9 C60

Rohs Exemption Information:

Yes

Control Type:

toggle

Trip Unit Technology:

thermal-magnetic

Local Signalling:

ON/OFF indication

Connections - Terminals:

tunnel type terminal top or bottom) 1-25 mm² - rigid || tunnel type terminal top or bottom) 1-25 mm² - flexible || tunnel type terminal top or bottom) 1-25 mm² - flexible with ferrule
