Schneider Electric MJL26400 Molded Case Circuit Breaker 600V 400A

(No reviews yet) Write a Review
SKU:
MJL26400
UPC:
785901879817
Condition:
New
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Mounting Mode:
unit mount lug)
Environmental Disclosure:
ENVPEP2206030EN
Quality Labels:
CE
Ambient Air Temperature For Operation:
-25-70 °C
Mounting Support:
lug
Sustainable Offer Status:
Green Premium product
Electrical Connection:
lugs, load || lugs, line
Continuous Current Rating:
0.8
Network Frequency:
50/60 Hz
Utilisation Category:
category A
Trip Unit Technology:
electronic, basic, ET 1.0,
Operating Altitude:
< 6561.68 ft (2000 m) without derating || 13123.36 ft (4000 m) with derating
Tightening Torque:
50-50 N.m 95-240 mm² (3 x AWG 3/0...3 x 500 kcmil)
California Proposition 65:
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
Color:
Black
Awg Gauge:
3 x AWG 3/0...3 x 500 kcmil aluminium/copper
Net Weight:
29 lb(US)
Quantity Per Set:
1
Eu Rohs Directive:
Compliant with Exemptions
Local Signalling:
1 trip indicator green)
Ip Degree Of Protection:
IP40
Suitability For Isolation:
yes IEC 60947-2
Breaking Capacity Code:
J
Magnetic Tripping Current:
800-4000 A
Pollution Degree:
3 IEC 60947-1
Ambient Air Temperature For Storage:
-50-85 °C
Depth:
8.05 in
Range:
PowerPact
Wire Stripping Length:
25 mm
Height:
12.86 in
Product Or Component Type:
circuit breaker
Breaking Capacity:
AIR 100 kA 240 V AC 50/60 Hz UL 489 || AIR 65 kA 480 V AC 50/60 Hz UL 489 || AIR 25 kA 600 V AC 50/60 Hz UL 489 || Icu 65 kA 240 V AC 50/60 Hz IEC 60947-2 || Icu 50 kA 380/415 V AC 50/60 Hz IEC 60947-2
Circuit Breaker Application:
HACR rated
[Uimp] Rated Impulse Withstand Voltage:
8 kV IEC 60947-2
Product Name:
PowerPact M
Warranty:
18 months
Long Time Pick-Up Adjustment Range:
300...800 A
Pvc Free:
Yes
Product Certifications:
UL || CSA || NOM
Trip Unit Name:
ET 1.0
[Ue] Rated Operational Voltage:
600 V AC 50/60 Hz UL 489
Line Rated Current:
400-400 A
[Ui] Rated Insulation Voltage:
750 V IEC 60947-2
[Ics] Rated Service Breaking Capacity:
35 kA 240 V AC 50/60 Hz IEC 60947-2 || 25 kA 380/415 V AC 50/60 Hz IEC 60947-2
Width:
8.27 in
Circularity Profile:
ENVEOLI2206030EN
Control Type:
operating handle
Rohs Exemption Information:
Yes
Device Application:
distribution
Number Of Slots:
2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 voltage release MN or MX plug-in)
Standards:
UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
Poles Description:
2P
Terminal Identifier:
AL800M23K
Mercury Free:
Yes
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Brochure:
View
Catalog:
View
Datasheet:
View
$7,829.00

Description

PowerPacT M-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT M-Frame circuit breakers have either a fixed long time electronic trip unit or an adjustable amperage version. This circuit breaker has an electronic trip unit, ET 1.0. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT M circuit breakers are available in 2 and 3-pole unit mount or I-Line construction. This unit has lugs on both the line and load sides. This PowerPacT M, 400A, 2 pole, circuit breaker has an interrupting rating of 25kA at 600VAC. This circuit breaker has a continuous current rating of 80%. PowerPacT M circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
