Schneider Electric NSYPLM86TVG 7035 Wm Plm847X636X300Glass 3Lock

(No reviews yet) Write a Review

Write a Review

Schneider Electric NSYPLM86TVG 7035 Wm Plm847X636X300Glass 3Lock

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

NSYPLM86TVG

UPC:

3606480776793

MPN:

Condition:

New

Lock Type:

3 points lock, handle with 1242E key lock

Environmental Disclosure:

ENVPEP110118EN

Enclosure Nominal Height:

847 mm

Ik Degree Of Protection:

IK08 IEC 62262

Circularity Profile:

N/A

Enclosure Nominal Depth:

300 mm

Product Or Component Type:

compact enclosure

Device Composition:

1 body || 1 door || 1 handle lock

Door Type:

transparent

Rohs Exemption Information:

Yes

Range:

Thalassa

Mounting Plate Description:

without mounting plate

Device Application:

multi-purpose

Eu Rohs Directive:

Pro-active compliance (Product out of EU RoHS legal scope)

Number Of Locks:

1

Color:

Gray RAL 7035)

Reach Regulation:

Reference contains Substances of Very High Concern above the threshold

Removable Parts:

door by hinges

Product Certifications:

UL

Ip Degree Of Protection:

IP66 IEC 60529

Ambient Air Temperature For Operation:

-40-80 °C

Device Short Name:

PLM

Electrical Insulation Class:

class II

Standards:

IEC 62208 || NEMA classification 4X || NEMA classification 13

Product Name:

Thalassa PLM

China Rohs Regulation:

Product out of China RoHS scope. Substance declaration for your information.

Enclosure Nominal Width:

636 mm

Enclosure Mounting:

wall mounted

Sustainable Offer Status:

Green Premium product

Mercury Free:

Yes

Material:

body polyester reinforced with fibreglass || door tempered glass

Accessibility For Operation:

front

Fire Resistance:

960 °C IEC 62208
