Schneider Electric NSYS3X12830 S3X 304L 1200X800X300

(No reviews yet) Write a Review

Write a Review

Schneider Electric NSYS3X12830 S3X 304L 1200X800X300

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

NSYS3X12830

UPC:

3606480155017

MPN:

Condition:

New

Ip Degree Of Protection:

IP66 IEC 60529

Environmental Characteristic:

corrosive || specific hygiene

China Rohs Regulation:

Product out of China RoHS scope. Substance declaration for your information.

Reach Regulation:

Reference contains Substances of Very High Concern above the threshold

Device Composition:

1 body || 1 reinforcement frame drilled door || 1 door || 2 lock door

Material:

body and door stainless steel 304L || lock zamak || hinge stainless steel

Type Of Gland Plate:

without gland plate

Surface Finish:

body and door Scotch-Brite® brushed || lock chromium plated

Door Type:

Solid

Lock Type:

2 points lock, 3 mm double-bar

Environmental Disclosure:

ENVPEP2109018EN

Body Type:

single piece body, cross-shaped structure || gutter shaped front rail

Product Or Component Type:

compact enclosure

Standards:

IEC 62208

Enclosure Nominal Width:

800 mm

Range:

Spacial

Mounting Plate Description:

without mounting plate

Product Name:

Spacial S3X

Circularity Profile:

N/A

Door Opening Side:

reversible 120 °)

Ik Degree Of Protection:

IK10 IEC 62262

Removable Parts:

door by hinges

Accessibility For Operation:

front

Installation Accessory Type:

wall-mounting

Warranty:

18 months

Rohs Exemption Information:

Yes

Number Of Doors:

front face 1

Eu Rohs Directive:

Pro-active compliance (Product out of EU RoHS legal scope)

Device Application:

multi-purpose

Mercury Free:

Yes

Sustainable Offer Status:

Green Premium product

Net Weight:

43 kg

Enclosure Nominal Depth:

300 mm

Enclosure Nominal Height:

1200 mm

Product Certifications:

UL 508 type A || CAN/CSA 22

Catalog:

View

Datasheet:

View
