Schneider Electric

Schneider Electric QOB120VH1042 Miniature Circuit Breaker 120/240V 20A

(No reviews yet) Write a Review
SKU:
QOB120VH1042
UPC:
3606486144343
Condition:
New
Range Of Product:
QO
Circularity Profile:
N/A
Rohs Exemption Information:
Yes
Net Weight:
0.299 kg
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Product Certifications:
UL Listed || CSA
Circuit Breaker Type:
standard
Height:
76 mm
Toxic Heavy Metal Free:
Yes
Electrical Connection:
pressure plate
Product Or Component Type:
miniature circuit-breaker
Line Rated Current:
20 A
Tightening Torque:
4.6-4.6 N.m
Mercury Free:
Yes
Width:
38 mm
Awg Gauge:
AWG 14...AWG 8 copper or aluminium
Ambient Air Temperature For Operation:
40 °C
Depth:
74 mm
Eu Rohs Directive:
Compliant with Exemptions
[Ue] Rated Operational Voltage:
120/240 V AC || 120 V AC
Accessory / Separate Part Type:
shunt trip 12/24 V AC/DC
Circuit Breaker Application:
HACR rated
Sustainable Offer Status:
Green Premium product
Poles Description:
1P
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Number Of Spaces Required:
2
Mounting Mode:
bolt-on
California Proposition 65:
WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Warranty:
18 months
Breaking Capacity:
22 kA 120/240 V AC 50/60 Hz || 22 kA 120 V AC 50/60 Hz
Brochure:
View
Datasheet:
View
$261.00

Description

QO and QOB one, two, and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on AC systems. These circuit breakers have an over center, trip free toggle mechanism with quick make, quick break action and positive handle indication. They also have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit. This 1 pole QO circuit breaker is rated at 20A at 120/240VAC. This unit provides 22kA breaking capacity and is bolt on mounting. A full line of features and factory installed accessories are also available such as shunt trips, auxiliary switches and alarm switches. This product includes an AC/DC shunt trip. QO circuit breakers are UL Listed under UL File E84967 and are CSA Certified under CSA Master Contract 153555.
