Schneider Electric QOB1701200 Miniature Circuit Breaker 240V 70A

(No reviews yet) Write a Review

Write a Review

Schneider Electric QOB1701200 Miniature Circuit Breaker 240V 70A

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

QOB1701200

UPC:

7.85901E+11

MPN:

Condition:

New

Product Or Component Type:

miniature circuit-breaker

Range Of Product:

QO

Eu Rohs Directive:

Compliant with Exemptions

Ambient Air Temperature For Operation:

40 °C

Awg Gauge:

AWG 8...AWG 2 copper or aluminium

Tightening Torque:

5-5 N.m

Line Rated Current:

70 A

Circuit Breaker Type:

standard

[Ue] Rated Operational Voltage:

120/240 V AC || 120 V AC

Reach Regulation:

Reference contains Substances of Very High Concern above the threshold

Poles Description:

1P

Toxic Heavy Metal Free:

Yes

Circuit Breaker Application:

HACR rated

California Proposition 65:

WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Depth:

74 mm

Electrical Connection:

box lugs

Rohs Exemption Information:

Yes

Mounting Mode:

bolt-on

Breaking Capacity:

10 kA 120/240 V AC 50/60 Hz || 10 kA 120 V AC 50/60 Hz

Net Weight:

0.227 kg

Height:

79 mm

China Rohs Regulation:

Product out of China RoHS scope. Substance declaration for your information.

Mercury Free:

Yes

Width:

38 mm

Product Certifications:

UL Listed || CSA

Number Of Spaces Required:

2

Accessory / Separate Part Type:

auxiliary switch 120 V AC 1A

Brochure:

View

Catalog:

View

Datasheet:

View
