Schneider Electric QOB325VH1021 Miniature Circuit Breaker 240V 25A

(No reviews yet) Write a Review

Write a Review

Schneider Electric QOB325VH1021 Miniature Circuit Breaker 240V 25A

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

QOB325VH1021

UPC:

3606486145555

MPN:

Condition:

New

Eu Rohs Directive:

Compliant with Exemptions

Poles Description:

3P

[Ue] Rated Operational Voltage:

120/240 V AC || 240 V AC || 120 V AC

Rohs Exemption Information:

Yes

Electrical Connection:

pressure plate

Sustainable Offer Status:

Green Premium product

Mounting Mode:

bolt-on

Width:

76 mm

Circuit Breaker Application:

HACR rated

Depth:

74 mm

China Rohs Regulation:

Product out of China RoHS scope. Substance declaration for your information.

Awg Gauge:

AWG 14...AWG 8 copper or aluminium

Breaking Capacity:

22 kA 120/240 V AC 50/60 Hz || 22 kA 240 V AC 50/60 Hz || 22 kA 120 V AC 50/60 Hz

Accessory / Separate Part Type:

shunt trip 120/208/240 V AC

Range Of Product:

QO

Toxic Heavy Metal Free:

Yes

Reach Regulation:

Reference contains Substances of Very High Concern above the threshold

Number Of Spaces Required:

4

Warranty:

18 months

Mercury Free:

Yes

Line Rated Current:

25 A

Circularity Profile:

N/A

Product Or Component Type:

miniature circuit-breaker

California Proposition 65:

WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Height:

76 mm

Ambient Air Temperature For Operation:

40 °C

Circuit Breaker Type:

standard

Net Weight:

0.549 kg

Product Certifications:

UL Listed || CSA

Tightening Torque:

4.6-4.6 N.m

Brochure:

View

Datasheet:

View
